Reference
Information
This section provides information about:
•
•
Specifications
Video
MTP input
Gain ........................................ Unity
Maximum resolution
Analog ............................... Up to 2048x1080 or 1080p @ 60 Hz
Signal transmission distance, analog
HDMI digital input
Maximum data rate ................. 4.95 Gbps (1.65 Gbps per color)
Maximum pixel clock ............... 165 MHz
Maximum resolution
Digital ................................ Up to 1920x1200 or 1080p @ 60 Hz
Signal transmission distance, digital
NOTE: The transmission distance varies greatly depending on the signal resolution and on the type of cable,
graphics card, and display used in the system.
Formats ................................... RGB and YCbCr digital video
Standards ................................ DVI 1.0, HDMI 1.2
Specifications
Part Numbers and Accessories
Analog Signal Maximum Transmission Distances
Resolutions
1024x768 @ 60 Hz
1920x1200, 2048x1080
1080p @ 60 Hz
Digital Signal Maximum Transmission Distances
Resolutions
1024x768,
720p, 1080i @ 60 Hz
1600x1200, 1920x1200,
1080p @ 60 Hz
MTP/HDMI U R
Up to 600' (183 m)
Up to 400' (122 m)
MTP/HDMI U R
8-bit Color Depth
CAT 5/5e/6 Cable
UTP STP
200' (60 m) 200' (60 m)
100' (30 m) 125' (38 m)
MTP/HDMI U R • Reference Information
Extron DTP26
Cable
200' (60 m)
150' (46 m)
