Chapter 6—Bottom Cover

6.1 Bottom Cover

Description
Bottom cover
Accessory cover
Rubber foot (4)
Screw (4)
48
The bottom cover assembly is fitted to the base frame using four Phillips
screws. An accessory cover, which facilitates installation of an optional
paper cutter, is snapped-locked to the bottom cover. Four rubber feet are
glued to the bottom plate, which also has four screw pockets that allow the
printer to be permanently attached to a table or similar.
Screw pockets
