4.2 LED and Feed Switch

Description
Replacement
Cable cover
Isolation sheet
Feed switch PCB
Intermec EasyCoder PC41—Service Manual
The LED control lamp and Feed switch are fitted on the same Feed Switch
PCB inside a housing on the left side of the print frame. The board is
connected to J6 on the main board via four cables that run inside the left
side hinge of the print frame. The control lamp shines through a transpar-
ent window and the Feed switch is activated via a dome, both in the name
plate on the top cover.
Color
Green (solid)
Green (flashing)
Red (solid)
Red (flashing)
Orange (solid)
Orange (flashing)
Dark
The Feed Switch PCB can be accessed for replacement by removing the
cable cover, which is held in place by a Phillips screw and a snap lock. The
Feed Switch PCB is inserted between two rails in the moulding and is cov-
ered by an isolation sheet.
Screw
Print frame
Meaning
Ready
Receiving data
System fault
Overtemperature
Media fault
Paused
Power off
Chapter 4 —Print Fram
Snap lock
19
