Name plate
Tear-off plate
3.2 Tear-Off Plate
Intermec EasyCoder PC41—Service Manual
The top cover is made up of the following parts:
• Top cover plastic moulding
• Clear plastic window (permanently glued to the moulding)
• Two media load instruction labels
• Tear-off plate (snap-locked to the moulding)
• Name plate (glued to the moulding)
The only part that can be replaced easily is the tear-off plate. It is provided
with two snap-lock tabs that engage bars at the inside of the top cover. Two
L-shaped rails hold the plate. If you need to remove the tear-off plate with-
out discarding it, be careful not to break the tabs, which are quite delicate.
Chapter 3—Top Cover
Top cover moulding
Clear window
15
