WEBVIEWER*
S e t u p > N e t w o r k > C o m m u n i c a t i o n P r o t o c o l
C u r r e n t P r o t o c o l d i s p l a y s t h e c u r r e n t s e l e c t e d p r o t o c o l .
1. To change the Protocol, select one of the three options—TCP, UDP, or Multicast.
2. If you select Multicast, enter the Multicast IP and Multicast Port.
3. Reboot your system to apply the changes to your camera. To Reboot, select Apply. A dialogue box
will appear, select OK. System will automatically restart and may take up to 20 seconds to reboot.
[1]
[2]
