Video - Digital Watchdog MEGApix DWC-MPTZ20XFM User Manual

WEBVIEWER*
S e t u p > V i d e o > P r i v a c y Z o n e
T h e M E G A P I X c a m e r a o f f e r s u p t o 2 4 p r i v a c y z o n e s e t t i n g s . T o s e t
P r i v a c y Z o n e s :
1. Move the camera to the position where you would like to setup a privacy masking.
2. Select the masking zone you would like to setup from the number drop-down options. If a privacy
zone has not been setup previously, [Undefined] will appear next to the zone's number.
3. Adjust the zone's size by selecting a value from the drop down menus.
a. Select the Width of the mask. Values range from 1- 30. if 30 is selected, the mask will be
the width of the camera's entire FoV.
b. Select the Height of the mask. Values range from 1- 30. if 30 is selected, the mask will be
the height of the camera's entire FoV.
4. The privacy masking by default will be set to the center of the FoV and will be gray.
5. Press Set to apply the mask to the
camera's view.
6. Press Delete to delete current mask.
7. Press Reload to display the last
saved settings.
4 9
[1]
[2]
[3]
[5]
[6]
[7]
[4]
