WEBVIEWER*
S e t u p > V i d e o > C o l o r S e t t i n g s
I n i t i a l l y , t h e f a c t o r y d e f a u l t s e t t i n g s w i l l a p p e a r ; h o w e v e r , y o u m a y
c u s t o m i z e t h e C o l o r S e t t i n g s f o r y o u r M E G A P I X c a m e r a .
Auto Exposure:
1. Slow Shutter Mode- Slow shutter mode decreases the shutter speed in low light to improve the
image quality. Turn to AUTO or Off. Default setting is AUTO. If the shutter mode is set to auto,
shutter speed is automatically set to match the environment's lighting settings.
2. BLC Mode- Select to enable or disable Backlight Compensation to adjust the image in harsh
lighting environments. Enable this option if there is a bright spot of light in the camera's FoV
that may cause other areas to appear too dark. Default setting is OFF.
3. Shutter Speed- Set the amount of light allowed in the video from the different speeds available.
The larger the value (1/1) the brighter the image will appear. The smaller the value (1/10000)
the darker the image will appear. Default
value is 1/30.
4. Brightness- Select from 0 (darkest) to
31 (brightest). Default value is 17.
5. Gain- Maximum light gain settings in
low light conditions. Select from -3dB
(least light) to 28dB (most light). Default
value is 6dB.
6. Iris- The Iris of the camera can be
controller manually by selecting a value
from the drop-down menu. The higher
the number (F1.4), the darker the
image. Default value is F1.6.
7. Select 'Apply' to save changes, 'Reload'
to return to the last saved settings, or
'Default' to return all settings to factory
default values.
