WEBVIEWER*
S e t u p > P T Z > S w i n g
U s e t h i s s e t u p m e n u t o c o n f i g u r e a n d m o d i f y t h e c a m e r a ' s S w i n g
f e a t u r e . W h e n t h e s w i n g f u n c t i o n r u n s , t h e c a m e r a m o v e s b e t w e e n
t w o ( 2 ) a s s i g n e d p o s i t i o n s b a s e d o n t h e d i r e c t i o n s e t b y t h e u s e r .
T h e c a m e r a s u p p o r t s u p t o 8 S w i n g p a t t e r n s . T o s e t u p a S w i n g :
6. Select the Dwell time. This value indicates how long the camera will remain on each position
before moving to the next position. Select from 1 to 60 seconds. Default is 1.
7. Select the direction of movement. Default is Shortest.
a. If shortest is selected, the camera will move from First Position to End Position and back
in the shorted available path.
b. If Clockwise is selected, the
camera will move from First
Position to End Position
Clockwise and from End
Position to First Position
Counter-Clockwise.
c. If Counter- Clockwise is
selected, the camera will
move from First Position to
End Position Counter-
Clockwise and from End
Position to First Position
Clockwise.
* See page 41 for more information on how to control swings from the camera's main viewer page.
