INSTALLATION - FLUSH MOUNT*
8.
Once all the cables are properly connected to the camera, close the Flush Mount cover by
attaching the connectors to the side of the flush mount.
9.
Insert the in-ceiling housing into the ceiling hole and press the edge of the housing against the
ceiling.
10. Secure the in-ceiling housing in place by turning the clip bolts located on the housing
Clockwise. .
2 4
