Digital Watchdog MEGApix DWC-MPTZ20XFM User Manual page 43

WEBVIEWER*
S e t u p > V i d e o > C o l o r S e t t i n g s
I n i t i a l l y , t h e f a c t o r y d e f a u l t s e t t i n g s w i l l a p p e a r ; h o w e v e r , y o u m a y
c u s t o m i z e t h e C o l o r S e t t i n g s f o r y o u r M E G A P I X c a m e r a .
White Balance: Also known as Color Balance. This gives the camera a reference to "true white."
White Balance is used to make colors appear the same in the Field of View (FoV) no matter what
is the light temperature of the light source. Select from Auto, or Manual.
If AUTO is selected, the camera will automatically adjust itself to the proper white balance.
If MANUAL is selected, adjust the following values:
- White Balance Red Offset- select from 0~255 range. The lower the number, the image will
appear green. The higher the number, the image will appear red. Default value is 210.
- White Balance Blue Offset- select from 0~255 range. The lower the number, the image will
appear yellow. The higher the number, the image will appear blue. Default value is 160.
Select: 'Apply' to save changes,
'Reload' to return to the last saved settings,
or 'Default' to return all settings to their
factory default values.
[White Balance Settings]
4 3
