Digital Watchdog MEGApix DWC-MPTZ20XFM User Manual page 48

WEBVIEWER*
S e t u p > V i d e o & A u d i o > A u d i o
C o n n e c t s p e a k e r / m i c r o p h o n e w i r e s ( n o t i n c l u d e d ) t o y o u r c a m e r a a n d t o a
m o n i t o r i n g d e v i c e ( e x . : P C c o m p u t e r ) .
1. On the Display Screen in your Web Viewer, go to Setup, Video & Audio, and finally, Audio. Adjust
settings to your preference.
a. Audio Input: Set Gain (0-5)
b. Audio Output: Set Buffering Time & Volume (0-5)
c. Network Transfer: Select Transfer Audio regardless of video.
d. Select Apply to save changes.
2. On the Display Screen, change Audio (in the bottom left corner) from OFF to 1. This will enable
you to hear external audio.
3. To transfer audio to the camera, select the 'headset' button beneath Audio.
[1]
[2]
[a]
[b]
[c]
[d]
[3]
4 8
