INSTALLATION*
5. Remove the PTZ mechanism from the upper housing to connect all necessary cables.
6. To detach camera mechanism, press down and hold both black handles on the camera
mechanism. Pull them up to detach the camera.
7. Remove the tape used to fix the PTZ mechanism after detaching the PTZ mechanism from the
upper housing. This was used to protect the camera's lens during shipping and should be
removed before turning the camera's power on.
[5]
[6]
[7]
