WEBVIEWER*
S e t u p > P T Z > T o u r
U s e t h i s s e t u p m e n u t o c o n f i g u r e a n d m o d i f y t h e c a m e r a ' s T o u r f e a t u r e .
T h e T o u r f u n c t i o n a l l o w s u s e r s t o r u n s e q u e n c e s o f p r e s e t s a n d s w i n g s .
E a c h t o u r c a n h a v e a m a x i m u m o f 2 0 a c t i o n . T h e M P T Z 2 0 X s u p p o r t s u p t o
8 T o u r s ( G r o u p s ) . T o s e t u p a T o u r :
1. Select the Tour/ Group number from the
drop down menu at the top left corner
of the setup page.
2. Assign a function to each action value. Select:
a. Preset# 1~255
b. Swing# 1~8
3. Set the dwell time for each action.
Select from 1 to 60 seconds. This
value indicates how long the
camera will remain on the preset
before moving to the next one.
Default is 5 Seconds.
4. Set the number of times the action
will be repeated in the tour before
moving to the next action. This
setup is for Swing options only.
Default is 1.
5. Click 'Apply' to save the changes.
* You must have at least two (2) presets and one (1) Swing set to properly setup a Tour.
** See page 41 for more information how to control Tours from the camera's main viewer page.
