Auto Resume After Power Failure; Live Viewing - Optiview VRHT Quick Start Up Manual

In the main menu, click shutdown button, you can see an interface is shown as below. See
Figure 2-4.
There are several options for you. See Figure 2-5.
The other ways is to press power button on the front panel for at least 3 seconds, system will
stop all operations. Then you can click the power button in the front panel to turn off the DVR.
Please note, before you replace the HDD, do remember shutting down the device and unplug
the power cable.

2.1.4 Auto Resume after Power Failure

The system can automatically backup video and resume previous working status after
power failure.

2.2 Live Viewing

After you logged in, the system is in live viewing mode by default. You can see system date,
time and channel name. If you want to change system date and time, you can refer to general
settings (Main Menu->Setting->General). If you want to modify the channel name, please refer
to the display settings (Main Menu->Setting->Display)
1
Recording status
2
Motion detection
Tips
z
Preview drag: If you want to change position of channel 1 and channel 16 when you
are previewing, you can left click mouse in the channel 1 and then drag to channel 16,
release mouse you can switch channel 1 and channel 16 positions.
z
Use mouse middle button to control window split: You can use mouse middle button
to switch window split amount.
Preview Control
The preview control function has the following features.
z
Support preview playback.
— In the preview desktop, system can playback previous 5-60 minutes record of
current channel. Please go to the Main Menu->General to set real-time
playback time.
— Support drag and play function. You can use your mouse to select any
playback start time.
Figure 2-4
Figure 2-5
3
Video loss
4
Camera lock
9
