4. Turn the device upside down
and then turn the screws in
firmly.
7. Put the cover in accordance
with the clip and then place the
upper cover back.
Important
When there is a bracket, please make sure the installation direction of HDDs is the same.

1.5 Front Panel

Please note the following introduction is based on the general 1U series only. For detailed
information, please refer to our resource CD included in your package for electronic
version of the User's Manual.
The front panel is shown as in Figure 1-1.
Please refer to the following sheet for front panel button information.
Name
Power button
Number button
5.
Fix the HDD firmly.
8. Secure the screws in the
rear panel and the side panel.
Figure 1-1
Icon
Power button, press this button for three seconds to
boot up or shut down DVR.
z
Number 0-9 and
z
etc
6. Connect the HDD cable and
power cable.
Function
Input Arabic number
Switch channel
