2.4 Search & Playback
Click search button in the main menu, search interface is shown as below. See Figure 2-12.
Usually there are three file types:
z
R: Regular recording file.
z
A: External alarm recording file.
z
M: Motion detection recording file.
Please refer to the following sheet for more information.
SN Name
Display
1
window
Search
2
type
3 Calendar
Playback
4
mode
Figure 2-12
zHere is to display the searched picture or file.
zSupport 1/4/9/16-window playback.
zHere you can select to search the picture or the recorded file.
zYou can select to play from the read-write HDD, from peripheral device or from
redundancy HDD.
zBefore you select to play from the peripheral device, please connect the
corresponding peripheral device. You can view all record files of the root directory
of the peripheral device. Click the Browse button; you can select the file you want
to play.
Important
zRedundancy HDD does not support picture backup function, but it
supports picture playback function. You can select to play from redundancy
HDD if there are pictures on the redundancy HDD.
zThe blue highlighted date means there is picture or file. Otherwise, there is no
picture or file.
zIn any play mode, click the date you want to see, you can see the corresponding
record file trace in the time bar.
zPlayback mode：1/4/9/16. (It may vary due to different series.)
— In 1-window playback mode: you can select 1-16 channels.
Function
13
