Logout; Auto Resume After Power Failure; Live Viewing; Schedule - Optiview VR LT Quick Start Up Manual

2.1.3

Logout

There are two ways for you to log out. You can use the OSD menu or the power button of the DVR system.
a. Logout Option 1: from the main menu, click shutdown button, select "logout...." from the drop-down box
then click OK. See Figure 2-3.
Other options at the "shutdown" menu . See Figure 2-4.
b. Logout Option 2: press power button at the front panel for at least 3 seconds to stop all system
operations, then you can press the power button at the front panel to turn off the DVR.

2.1.4 Auto Resume after Power Failure

The DVR system will automatically record video and resume previous working status after power failure.

2.2 Live Viewing

After you logged in, by default, the system will be in live viewing mode. The system date, time and channel name
will be displayed on the screen. If you want to change the system date and time, refer to general settings (Main
Menu->Setting->General). If you need to modify the channel name, please refer to the display settings (Main
Menu->Setting->Display)
1
Recording status
2
Motion detection

2.3 Schedule

Note:
You need to have proper rights to implement the Schedule. Make sure the HDDs have been properly
installed. After the system boot up, it is in default 24-hour regular mode. You can set record type and time
schedule at the schedule menu interface.
Figure 2-2
Figure 2-3
Figure 2-4
3
Video loss
4
Camera lock
15
