Multiple-Channel Preview - Optiview VRHT Quick Start Up Manual

Note
z
After you go to the mark management interface, system needs to pause current playback.
System resumes playback after you exit mark management interface.
z
If the mark file you want to playback has been removed, system begin playbacking from the
first file in the list.

2.4.4 Multiple-channel Preview

Right click mouse and then select multiple-channel preview; you can go to the following
interface. See Figure 2-17. Here you can enable and set multiple-channel preview so that
you can view several video at one channel.
z
Enable: Check the box here to enable this function.
z
Storage: This function is null right now.
z
Frame rate: PAL：1-25fps.NTSC:30fps.
z
Bit stream value: Default setup is 1024Kb/S.
In the main menu, from Setting to Schedule, you can go to schedule menu. See Figure 2-18.
There are total six periods.
Channel: Please select the channel number first. You can select "all" if you want to set for
z
the whole channels.
z
Week day: There are eight options: ranges from Saturday to Sunday and all.
z
Pre-record: System can pre-record the video before the event occurs into the file. The value
ranges from 1 to 30 seconds depending on the bit stream.
z
Redundancy: System supports redundancy backup function. You can highlight Redundancy
button to activate this function. Please note, before enable this function, please set at least
one HDD as redundant. (Main menu->Advanced->HDD Management).
Please note this function is null if there is only one HDD.
z
Snapshoot: You can enable this function to snapshoot image when alarm occurs.
z
Record types: There are four types: regular, motion detection (MD), Alarm, MD & alarm.
z
Holiday setting: Click it you can see an interface shown as in Figure 2-19. Here you can set
holiday date. Check the box, it means current channel shall record as your holiday setup.
Please go to the Period interface to set the holiday date record setup. You can enable
holiday function on General interface and go to Schedule interface to enable holiday setup of
a channel.
Figure 2-17
19
