NIC1/2 LED

HDD LED

Power LED

007-6307-001
Figure 4-6 NIC1/2 LED
Indicates network activity on LAN1/2 when flashing.
Figure 4-7 HDD LED
This light indicates SATA and/or DVD-ROM drive activity when flashing.
Figure 4-8
Power LED
Indicates power is being supplied to the system's power supply units. This LED should normally
be illuminated when the system is operating.
