007-5841-001
6. Place the PCIe bracket assembly back into the server chassis while carefully inserting the
riser card back into the system serverboard slot. See
7. Secure the expansion card bracket to the chassis with the three screws removed in step 4.
8. Connect cables to the add-on card as necessary, replace the system cover and plug in the
power cords prior to rebooting the server.
Figure 6-11
Remove/Replace Full-height PCIe Card in Bracket
Install/Replace a PCIe Expansion Card
Figure 6-12 on page 58
for an example.
57
