3.
Overview
007-5841-001
Chapter 3
System Interface
There are several LEDs on the front control panel as well as others on the drive carriers and power
supplies to keep you constantly informed of the overall status of the system. See Figure 3-1 for an
example of the front control panel. These LEDs provide constant information on the system and
on the overall health of system components.
2
1
!
Figure 3-1
System Front Control Panel Indicator Components
19
