007-5841-001
4. Secure the drive to the carrier with four screws. Use the M3 flat-head screws included in the
HDD bag of your accessory box. Note: the screws used to secure a dummy drive to the
carrier should not be used to secure the hard drive.
5. Insert the hard drive carrier assembly into its bay vertically, keeping the carrier oriented so
that the release button is on the bottom. When the carrier reaches the rear of the drive bay,
the handle will retract.
6. Using your thumb, push against the upper part of the hard drive handle until the assembly
clicks into the locked (fully seated) position, see
Note: Your operating system must have RAID support to enable the hot-plug capability of the
drives.
Caution: Regardless of how many hard drives are installed, all drive carriers must remain in the
drive bays to maintain proper airflow and system cooling.
Drive Bay Installation/Removal
Figure 6-3 on page 47
for an example.
45
