System Operating And Regulatory Overview; Operating Environment; System Input Requirements; Power Supply - Silicon Graphics Rackable C2110G-RP5 System User's Manual

B.

Operating Environment

System Input Requirements

Power Supply

007-5841-001
Appendix B

System Operating and Regulatory Overview

This appendix provides basic environmental operating requirements and regulatory information
for the server.
Operating Temperature: 10º to 35º C (32º to 95º F)
Non-operating Temperature: -40º to 70º C (-40º to 158º F)
Operating Relative Humidity: 8% to 90% (non-condensing)
Non-operating Relative Humidity: 5% to 95% (non-condensing)
AC Input Voltage: 180-240 VAC
Rated Input Current: 1000W: 100-120V/12-10A, 1200W: 120-140V/12-10A,
1800W: 200-240V/10-8.5A
Rated Input Frequency: 50-60 Hz
Rated Output Power: 1800W
Rated Output Voltages: +12V (150A), +5Vsb (4A)
63
