1St Mb Memory Map; Interrupt Assignments - Data Modul MIO-2261 User Manual

C.3

1st MB Memory Map

Table C.3: 1st MB Memory Map
Addr. Range (Hex)
E0000h - FFFFFh
D0000h - DFFFFh
C0000h - CFFFFh
A0000h - BFFFFh
A0000h - BFFFFh
00000h - 9FFFFh
C.4

Interrupt Assignments

Table C.4: Interrupt Assignments
Interrupt#
NMI
IRQ0
IRQ1
IRQ2
IRQ3
IRQ4
IRQ5
IRQ6
IRQ7
IRQ8
IRQ9
IRQ10
IRQ11
IRQ12
IRQ13
IRQ14
IRQ15
Device
System board
PCI Bus
System board
PCI Bus
Intel® HD Graphic
System board
Interrupt Source
Parity error detected
System timer
Standard 101/102-Key or Microsoft Natural PS/2 Keyboard
Interrupt from controller 2 (cascade)
Communications Port (COM2)
Communications Port (COM1)
Available
Available
Available
System CMOS/real time clock
Microsoft ACPI-Compliant System
Available
Available
PS/2 Compatible Mouse
Numeric data processor
Primary IDE
Secondary IDE
