CN1
Part Number
Footprint
Description
Pin
1
2
CN2
Part Number
Footprint
Description
Pin
1
2
CN3
Part Number
Footprint
Description
Pin
CN4
Part Number
Footprint
Description
Pin
1
2
3
4
5
6
7
8
9
10
12 V Power Input
1655003962
WF_2P_156_D_A3963WV2
Pin Name
+12 V
GND
DC JACK (by request)
1652005684
PJ_3P_DCJ-RPBT5NW-25
Pin Name
+VIN
GND
DDR3 SO-DIMM
1651002083
DDR3_204P_AS0A626-JA
Pin Name
GPIO
1653005261
HD_5x2P_79
PIN HEADER SMD 5*2P 180D(M) 2.0 mm
Pin Name
+5 V
GPIO4
GPIO0
GPIO5
GPIO1
GPIO6
GPIO2
GPIO7
GPIO3
GND
47
