C.1

System I/O Ports

Table C.1: System I/O Ports
Addr. Range (Hex)
000-01Fh
20h-2Dh
50h-52h
060h-06Fh
070h-07Fh
080h-09Fh
0A0h-0BFh
0C0h-0DFh
F0C0h-F0C7h
F0E0h-F0E7h
2F8h-2FFh
3C0h-3DFh
3F8h-3FFh
400h-4FFh
500h-53Fh
600h-67Fh
C.2

DMA Channel Assignments

Table C.2: DMA Channel Assignments
Channel
0
1
2
3
4
5
6
7
MIO-2261 User Manual
Data Modul AG - www.data-modul.com
Device
DMA Controller
Interrupt Controller
Timer/Counter
8042 (keyboard controller)
Real-time clock, non-maskable interrupt (NMI) mask
DMA page register
0A0-0BF
DMA controller
IDE Controller
IDE Controller
Communications Port (COM2)
Motherboard resources
Communications Port (COM1)
Motherboard resources
Motherboard resources
Motherboard resources
Function
Available
Available
Available
Available
Direct memory access controller
Available
Available
Available
70
