Page 1: User Manual
User Manual 1st Ed - Version: January 2013... - Page 2 SMI is a trademark of Silicon Motion, Inc. Creative is a trademark of Creative Technology LTD. All other product names or trademarks are properties of their respective owners. Part No. 2006226110 Edition 1 Printed in China May 2012 MIO-2261 User Manual Data Modul AG - www.data-modul.com...
- Page 3 – Description of your peripheral attachments – Description of your software (operating system, version, application software, etc.) – A complete description of the problem – The exact wording of any error messages MIO-2261 User Manual Data Modul AG - www.data-modul.com...
-
Page 4: Packing List
Intel® Atom™ N2800, fanless, LVDS, VGA, Gigabit Ethernet, 4 USB, mSATA, SMBus, GPIO, 2 COM, mini PCIe, MIOe Optional Accessories Part No. Description 1960055791T001 Heat Spreader (99.5 x 70.5 x 11.2 mm) MIO-2261 User Manual Data Modul AG - www.data-modul.com... -
Page 5: Declaration Of Conformity
Do not attempt to recharge, force open, or heat the battery. Replace the battery only with the same or equivalent type recommended by the man- ufacturer. Discard used batteries according to the manufacturer's instructions. MIO-2261 User Manual Data Modul AG - www.data-modul.com... -
Page 6: Safety Instructions
The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. MIO-2261 User Manual Data Modul AG - www.data-modul.com... - Page 7 PC is on. Disconnect power before making any configuration changes. The sudden rush of power as you connect a jumper or install a card may damage sensitive elec- tronic components. MIO-2261 User Manual Data Modul AG - www.data-modul.com...
- Page 8 MIO-2261 User Manual viii Data Modul AG - www.data-modul.com...
-
Page 9: Table Of Contents
Figure 3.2 Main setup screen ............ 21 3.2.2 Advanced BIOS Features Setup..........22 Figure 3.3 Advanced BIOS features setup screen ....22 Figure 3.4 ACPI Setting ............. 22 Figure 3.5 TPM Configuration............ 23 MIO-2261 User Manual Data Modul AG - www.data-modul.com... - Page 10 DMA Channel Assignments ..............70 Table C.2: DMA Channel Assignments ........70 1st MB Memory Map................71 Table C.3: 1st MB Memory Map ..........71 Interrupt Assignments ................71 Table C.4: Interrupt Assignments ..........71 MIO-2261 User Manual Data Modul AG - www.data-modul.com...
-
Page 11: Chapter 1 General Introduction
Chapter General Introduction This chapter gives background information on the MIO-2261. Sections include: Introduction Product Features Specifications Data Modul AG - www.data-modul.com... -
Page 12: Introduction
MIO-2261 is a MI/O-Ultra SBC (Single Board Computer) with Embedded Intel® Atom™ N2600 1.6 GHz and N2800 1.86 GHz Processor. The MIO-2261 can support DDR3 memory up to 4 GB, has four USB 2.0 compatible ports, one GbE (up to 1000 Mbps) interface, LVDS and VGA support, HD (High Definition) audio, and one half size mini-PCIe and MIOe expansion slot. -
Page 13: Functional Specifications
Transmission speed up to 480 Mbps Full ACPI (Advanced Configuration and Power Interface) 3.0 Supports S1, S3, S4, S5 Power Management Support wake on LAN BIOS AMI EFI 16 Mbit Flash BIOS via SPI MIO-2261 User Manual Data Modul AG - www.data-modul.com... -
Page 14: Mechanical Specifications
N2800: 0.46 A@ 12 V (5.52 W) Max in Win7 HCT12 (10 minutes): N2600: 0.76 A @ 12 V (9.12 W) N2800: 0.80 A @ 12 V (9.6 W) 1.2.4.3 RTC Battery Typical Voltage: 3.0 V MIO-2261 User Manual Data Modul AG - www.data-modul.com... -
Page 15: Environmental Specifications
40 °C @ 95% RH Non-Condensing 1.2.5.2 Operating Temperature 0 ~ 60 °C (32~140 °F) 1.2.5.3 Storage Humidity 60 °C @ 95% RH Non-Condensing 1.2.5.4 Storage Temperature -40 ~ 85 °C (-40 ~ 185 °F) MIO-2261 User Manual Data Modul AG - www.data-modul.com... - Page 16 MIO-2261 User Manual Data Modul AG - www.data-modul.com...
-
Page 17: Chapter 2 H/W Installation
Chapter H/W Installation This chapter explains the setup procedures of the MIO-2261 hard- ware, including instructions on setting jumpers and connecting peripherals, as well as switches, indicators and mechanical draw- ings. Be sure to read all safety precautions before you begin the installation procedure. -
Page 18: Jumpers
Table 2.2: J1: LCD Power/Auto Power on Part Number 1653003260 Footprint HD_3x2P_79 Description PIN HEADER 3*2P 180D(M) 2.0mm SMD SOUARE PIN Setting Function (1-2) (3-4) (default) +3.3V (5-6) (default) Auto Power On MIO-2261 User Manual Data Modul AG - www.data-modul.com... -
Page 19: Connectors
Battery 2.2.2 Connector Settings 2.2.2.1 Battery Connector (BH1) MIO-2261 supports Lithium 3 V/210 mAH CR2032 battery with wire via battery con- nector (BH1). Note! How to clear CMOS: (Must follow below steps) 1. Turn off system power 2. Unplug CR2032 battery cable on BH1 3. - Page 20 2.2.2.8 Mini PCIe Connector (CN8) MIO-2261 supports a half size mini PCIe slot. PCI Express Mini Card (also known as Mini PCI Express, Mini PCIe, and Mini PCI-E) is a replacement for the Mini PCI form factor based on PCI Express. It is developed by the PCI-SIG. The host device sup- ports both PCI Express and USB 2.0 connectivity.
- Page 21 PCIe x1 lane via RJ-45 connector. 2.2.2.14 High Definition Audio Interface (CN15) MIO-2261 provides one 5x 2 pin box header for audio device. It can support high def- inition audio stereo by customized audio module that has codec onboard. 2.2.2.15 MIOe connector (CN16) MIO-2261 supports MIOe connector to extend flexible I/Os.
-
Page 22: Mechanical
Mechanical 2.3.1 Jumper and Connector Locations CN13 CN15 CN18 CN11 Figure 2.1 Jumper and Connector layout (Top side) CN14 CN16 CN17 CN12 CN10 CN4 Figure 2.2 Jumper and connector layout (Bottom side) MIO-2261 User Manual Data Modul AG - www.data-modul.com... -
Page 23: Board Dimensions
2.3.2 Board Dimensions 2.3.2.1 CPU Board Drawing unit: mm Figure 2.3 Board dimension layout (Top side) unit: mm Figure 2.4 Board dimension layout (Bottom side) MIO-2261 User Manual Data Modul AG - www.data-modul.com... -
Page 24: Figure 2.5 Board Dimension Layout (Top Side With Optional Dc Jack)
Figure 2.5 Board dimension layout (Top side with optional DC/Jack) unit: mm Figure 2.6 Board dimension layout (Bottom side with optional DC/Jack) MIO-2261 User Manual Data Modul AG - www.data-modul.com... -
Page 25: Figure 2.7 Board Dimension Layout (Coastline With Power Connec Tor And Heatsink)
Figure 2.7 Board dimension layout (coastline with power connector and heatsink) Figure 2.8 Board dimension layout (coastline with Power connector and optional heatspreader) Figure 2.9 Board dimension layout (coastline with heatsink and optional DC/ jack) MIO-2261 User Manual Data Modul AG - www.data-modul.com... -
Page 26: Figure 2.11Mi/O Module Height Constraint
Constraint of components' max. height of MI/O module base on 16 mm height MIOe connector. If needed, there's 19 mm height as well. The height of power connector (including of cable) on MIO-2261 should be considered when assembling the system or stacking the MI/O module. -
Page 27: Figure 2.12 Illustration Of Heat Spreader Assembly
2.3.2.3 Another Thermal Solution - Heat Spreader MIO-2261 has an optional heat spreader to make whole system more compact. Using a heat spreader to conduct heat to your chassis can help a lot when system is extra compact or limited space for heat convection. Here are some guidelines for... - Page 28 MIO-2261 User Manual Data Modul AG - www.data-modul.com...
-
Page 29: Chapter 3 Bios Settings
Chapter BIOS Settings Data Modul AG - www.data-modul.com... -
Page 30: Bios Setup
AMIBIOS has been integrated into many motherboards for over a decade. With the AMIBIOS Setup program, users can modify BIOS settings and control various sys- tem features. This chapter describes the basic navigation of the MIO-2261 BIOS setup screens. Figure 3.1 Setup program initial screen AMI's BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. -
Page 31: Entering Setup
System Date using the <Arrow> keys. Enter new values through the keyboard. Press the <Tab> key or the <Arrow> keys to move between fields. The date must be entered in MM/DD/YY format. The time must be entered in HH:MM:SS format. MIO-2261 User Manual Data Modul AG - www.data-modul.com... -
Page 32: Advanced Bios Features Setup
This item allows users to enable or disable launch storage OpROM if available. 3.2.2.1 Advantech BIOS Update V1.3 This item allows users to flash BIOS. 3.2.2.2 ACPI Settings Figure 3.4 ACPI Setting MIO-2261 User Manual Data Modul AG - www.data-modul.com... -
Page 33: Figure 3.5 Tpm Configuration
This item allows users to enable or disable S3 resume for VBIOS. 3.2.2.3 TPM Configuration Figure 3.5 TPM Configuration TPM Support Disable/Enable TPM if available. 3.2.2.4 CPU Configuration Figure 3.6 CPU Configuration MIO-2261 User Manual Data Modul AG - www.data-modul.com... -
Page 34: Figure 3.7 Sata Configuration
This item allows users to select mode of SATA controller(s). 3.2.2.6 Intel Fast Flash Standby Figure 3.8 Intel Fast Flash Standby IFFS Support This item allows users to enable or disable iFFS. MIO-2261 User Manual Data Modul AG - www.data-modul.com... -
Page 35: Figure 3.9 Usb Configuration
Host Controller. 'Auto' uses a default value: for a Root port it is 100 ms, for a Hub port the delay is taken from the Hub descriptor. 3.2.2.8 Super IO Configuration Figure 3.10 Super IO Configuration MIO-2261 User Manual Data Modul AG - www.data-modul.com... -
Page 36: Figure 3.11Hw Monitor Configuration
Figure 3.11 HW Monitor Configuration This page display all information about system Temperature/Voltage/Current. 3.2.2.10 AOAC Configuration Figure 3.12 AOAC Configuration AOAC Configuration This item allows users to enable or disabled AOAC function. MIO-2261 User Manual Data Modul AG - www.data-modul.com... -
Page 37: Figure 3.13Ppm Configuration
C4 state. C-state POPDOWN This item allows users to enable or disabled Intel C-state POPDOWN function. C-state POPUP This item allows users to enable or disabled Intel C-state POPUP function. MIO-2261 User Manual Data Modul AG - www.data-modul.com... -
Page 38: Chipset
3.2.3 Chipset Select the Chipset tab from the MIO-2261 setup screen to enter the Chipset BIOS Setup screen. You can display a Chipset BIOS Setup option by highlighting it using the <Arrow> keys. All Plug and Play BIOS Setup options are described in this sec- tion. -
Page 39: Figure 3.16South Bridge
NB and SB side of DMI link. High Precision Timer Enables or disables the high precision timer. SLP_S4 Assertion Width This item allows users to set a delay of sorts. Restore AC Power Loss MIO-2261 User Manual Data Modul AG - www.data-modul.com... -
Page 40: Figure 3.17Tpt Device
Enables for MSATA disables for PCIe. LAN1 Controller This item allows users to enables or disables LAN device. PCI Express PME This item allows users to enables or disables PCIe PME function. MIO-2261 User Manual Data Modul AG - www.data-modul.com... -
Page 41: Boot Settings
Option ROM Message Set display mode for option ROM. Interrupt 19 Capture This item allows option ROMs to trap interrupt 19. 1st/2nd/3rd/4th/5th/6th/7th Boot This item allows users to set boot device priority. MIO-2261 User Manual Data Modul AG - www.data-modul.com... -
Page 42: Security Setup
Security Setup Figure 3.19 Password Configuration Select Security Setup from the MIO-2261 Setup main BIOS setup menu. All Security Setup options, such as password protection is described in this section. To access the sub menu for the following items, select the item and press <Enter>: ... -
Page 43: Save & Exit
3.2.6.7 Restore Defaults The MIO-2261 automatically configures all setup items to optimal settings when users select this option. Optimal Defaults are designed for maximum system perfor- mance, but may not work best for all computer applications. In particular, do not use the Optimal Defaults if the user's computer is experiencing system configuration problems. - Page 44 BIOS setup menu. 3.2.6.9 Restore User Defaults The users can select this option to restore user defaults. 3.2.6.10 Boot Override You select device you want to do boot override. MIO-2261 User Manual Data Modul AG - www.data-modul.com...
-
Page 45: S/W Introduction & Installation
Chapter S/W Introduction & Installation Data Modul AG - www.data-modul.com... -
Page 46: S/W Introduction
API in SUSI. The hardware functions currently supported by SUSI can be grouped into a few categories including Watchdog, I C, SMBus, GPIO, and VGA control. Each category of API in SUSI is briefly described below. MIO-2261 User Manual Data Modul AG - www.data-modul.com... -
Page 47: Software Apis
However, due to the inaccuracy among many commercially available hardware mon- itoring chips, Advantech has developed a unique scheme for hardware monitoring - achieved by using a dedicated micro-processor with algorithms specifically designed MIO-2261 User Manual Data Modul AG - www.data-modul.com... -
Page 48: Susi Installation
If a previous version is located, please see the [Maintenance Setup] section. If it is not located, an alternative window appears. Click Next. 4.3.4 SUSI Sample Programs Sample Programs MIO-2261 User Manual Data Modul AG - www.data-modul.com... - Page 49 For a complete support list, please refer to Appendix A. We describe the steps to test all functions of this application. GPIO MIO-2261 User Manual Data Modul AG - www.data-modul.com...
- Page 50 The pin numbers are ordered bitwise, i.e. bit 0 stands for GPIO 0, bit 1 stands for GPIO 1, etc. For example, if you want to set pin 0 MIO-2261 User Manual Data Modul AG - www.data-modul.com...
- Page 51 Access multiple bytes mode must be written in decimal. You can test the functional- ities of the watchdog as follows: MIO-2261 User Manual Data Modul AG - www.data-modul.com...
- Page 52 Key in all the desired data in the Result field in hexadecimal format, divided by commas, for example, 0x50,0x60,0x7A. – Click the WRITE SMBus DATA button and all of the data will be written to the device through the SMBus. MIO-2261 User Manual Data Modul AG - www.data-modul.com...
- Page 53 UP button to increase the brightness. – Move the slider in decrements, using either the mouse or the direction keys, or click the DOWN button to decrease the brightness. Watchdog MIO-2261 User Manual Data Modul AG - www.data-modul.com...
- Page 54 If certain data values are not supported by the platform, the correspondent data field will be grayed-out with a value of 0. For more details on MIO-2261 software API, please contact your dealer or Advantech MIO-2261 User Manual...
-
Page 55: Appendix Apin Assignments
Appendix PIN Assignments Data Modul AG - www.data-modul.com... -
Page 56: Jumper Setting
Table A.3: J1: LCD Power/Auto Power On Part Number 1653003260 Footprint HD_3x2P_79 Description PIN HEADER 3*2P 180D(M) 2.0mm SMD SOUARE PIN Setting Function (1-2) +5 V (3-4) (default) +3.3 V (5-6) (default) Auto Power On MIO-2261 User Manual Data Modul AG - www.data-modul.com... - Page 57 1651002083 Footprint DDR3_204P_AS0A626-JA Description Pin Name GPIO Part Number 1653005261 Footprint HD_5x2P_79 Description PIN HEADER SMD 5*2P 180D(M) 2.0 mm Pin Name +5 V GPIO4 GPIO0 GPIO5 GPIO1 GPIO6 GPIO2 GPIO7 GPIO3 MIO-2261 User Manual Data Modul AG - www.data-modul.com...
- Page 58 Part Number 1654000055 Footprint DBVGA-VF5MS Description D-SUB Conn. 15P 90D(F) DIP 070242FR015S200ZU Pin Name GREEN BLUE DDAT HSYNC VSYNC DCLK MIO-2261 User Manual Data Modul AG - www.data-modul.com...
- Page 59 Part Number 00A00000770 Footprint MINIPCIE_HALF_PICO_ITX Description Pin Name +3.3V +1.5V +3.3V MIO-2261 User Manual Data Modul AG - www.data-modul.com...
- Page 60 Part Number 00A00000770 Footprint MINIPCIE_HALF_PICO_ITX Description Pin Name +1.5V SMB_CLK SMB_DAT USB D- USB D+ +3.3V +3.3V +1.5V +3.3V SATA Part Number 1654007578 Footprint SATA_7P_WATF-07DBN6SB1U Description Pin Name MIO-2261 User Manual Data Modul AG - www.data-modul.com...
- Page 61 Mini PCIe Part Number 00A00000660 Footprint MINIPCIE_HALF_PICO2600 Description Pin Name WAKE# +3.3VSB +1.5V REFCLK- REFCLK+ PERST# PERn0 +3.3VSB PERp0 MIO-2261 User Manual Data Modul AG - www.data-modul.com...
- Page 62 Pin Name +1.5 V SMB_CLK PETn0 SMB_DAT PETp0 USB D- USB D+ +3.3 VSB +3.3 VSB +1.5 V +3.3 VSB External USB Part Number 1654009513 Footprint USB_8P_UB1112C-8FDE-4F Description Pin Name +5 V MIO-2261 User Manual Data Modul AG - www.data-modul.com...
- Page 63 +5 V A_D- B_D- A_D+ B_D+ CN11 COM1/COM2 Part Number 1653003720 Footprint HD_10x2P_79_RA Description Pin Name DCD1# DSR1# RXD1 RTS1# TXD1 CTS1# DTR1# RI1# DCD2# DSR2# RXD2 RTS2# TXD2 CTS2# DTR2# RI2# MIO-2261 User Manual Data Modul AG - www.data-modul.com...
- Page 64 Pin Name SMB_DAT SMB_CLK +5 V CN13 Front Panel Part Number 1653004883 Footprint HD_3x2P_79_RA_21N22050 Description Pin Name Power Button Pin1 Power LED+ Power/Reset Button Pin2 HDD LED+ Reset Button Pin1 HDD LED- MIO-2261 User Manual Data Modul AG - www.data-modul.com...
- Page 65 Gigabit Ethernet Part Number 1652004356 Footprint RJ45_14P_RT7-194AAM1A Description Pin Name BI_DA+(GHz) BI_DA-(GHz) BI_DB+(GHz) BI_DC+(GHz) BI_DC-(GHz) BI_DB-(GHz) BI_DD+(GHz) BI_DD-(GHz) CN15 HD Audio Part Number 1653003719 Footprint HD_5x2P_79_RA_21N22050 Description Pin Name LOUTR LINR LOUTL LINL MIO-2261 User Manual Data Modul AG - www.data-modul.com...
- Page 66 CN16 MIOe Part Number 1654006235 Footprint BB_40x2P_32_1625x285_2HOLD Description Pin Name PCIE_RX0+ PCIE_TX0+ PCIE_RX0- PCIE_TX0- PCIE_RX1+ PCIE_TX1+ PCIE_RX1- PCIE_TX1- PCIE_RX2+ PCIE_TX2+ PCIE_RX2- PCIE_TX2- PCIE_RX3+ PCIE_TX3+ PCIE_RX3- PCIE_TX3- MIO-2261 User Manual Data Modul AG - www.data-modul.com...
- Page 67 MIO-2261 User Manual Data Modul AG - www.data-modul.com...
- Page 68 CN16 MIOe Part Number 1654006235 Footprint BB_40x2P_32_1625x285_2HOLD Description Pin Name PCIE_CLK+ LOUTL PCIE_CLK- LOUTR AGND SMB_CLK SMB_DAT PCIE_WAKE# RESET# SLP_S3# CLK33M LPC_AD0 DDP_HPD LPC_AD1 LPC_AD2 DDP_AUX+ LPC_AD3 DDP_AUX- LPC_DRQ#0 MIO-2261 User Manual Data Modul AG - www.data-modul.com...
- Page 69 MIO-2261 User Manual Data Modul AG - www.data-modul.com...
- Page 70 CN16 MIOe Part Number 1654006235 Footprint BB_40x2P_32_1625x285_2HOLD Description Pin Name LPC_SERIRQ DDP_D0+ LPC_FRAME# DDP_D0- USB0_D+ DDP_D1+ USB0_D- DDP_D1- USB1_D+/USB_SSTX+ DDP_D2+ USB1_D-/USB_SSTX- DDP_D2- USB2_D+/USB_SSRX+ DDP_D3+ USB2_D-/USB_SSRX- DDP_D3- USB_OC# MIO-2261 User Manual Data Modul AG - www.data-modul.com...
- Page 71 MIO-2261 User Manual Data Modul AG - www.data-modul.com...
- Page 72 CN16 MIOe Part Number 1654006235 Footprint BB_40x2P_32_1625x285_2HOLD Description Pin Name +12VSB +12VSB +5VSB +5VSB +5VSB +5VSB MIO-2261 User Manual Data Modul AG - www.data-modul.com...
- Page 73 CN17 Inverter Power/ Internal SATA Power Part Number 1655905100 Footprint WF_5P_49_BOX_RA Description Wafer 1.25mm 5P 90D Male SMD 852040 Pin Name +12V ENABKL MIO-2261 User Manual Data Modul AG - www.data-modul.com...
- Page 74 24 bits LVDS Panel Part Number 1655000753 Footprint WF14P_49_BOX_RA_85204-14001 Description Pin Name LVDS0_CLK- LVDS0_CLK+ LVDS0_D3- LVDS0_D3+ LVDS0_D2- LVDS0_D2+ LVDS0_D1- LVDS0_D1+ LVDS0_D0- LVDS0_D0+ +5 V or +3.3 V +5 V or +3.3 V MIO-2261 User Manual Data Modul AG - www.data-modul.com...
-
Page 75: Wdt & Gpio
Appendix WDT & GPIO Data Modul AG - www.data-modul.com... -
Page 76: Watchdog Timer Sample Code
+ 65h; mov al,080h out dx,al ;==================================================== ;66H ;WDT timer time-out value ;bit[7:0]=0~255 ;==================================================== mov dx,SCH3114_IO + 66h mov al,01h out dx,al ;==================================================== ;bit[0] status bit R/W ;WD timeout occurred =1 MIO-2261 User Manual Data Modul AG - www.data-modul.com... -
Page 77: Gpio Sample Code
;==================================================== mov dx,SCH3114_IO + 23h ;GPIO 0 mov al,00h ;Set GPIO 0 as output type out dx,al mov dx,SCH3114_IO + 4Bh mov al,01h ;Set GPIO 0 as high value. out dx,al .exit MIO-2261 User Manual Data Modul AG - www.data-modul.com... - Page 78 MIO-2261 User Manual Data Modul AG - www.data-modul.com...
-
Page 79: Appendix C System Assignments
Appendix System Assignments Data Modul AG - www.data-modul.com... -
Page 80: System I/O Ports
Communications Port (COM1) 400h-4FFh Motherboard resources 500h-53Fh Motherboard resources 600h-67Fh Motherboard resources DMA Channel Assignments Table C.2: DMA Channel Assignments Channel Function Available Available Available Available Direct memory access controller Available Available Available MIO-2261 User Manual Data Modul AG - www.data-modul.com... -
Page 81: 1St Mb Memory Map
Available IRQ6 Available IRQ7 Available IRQ8 System CMOS/real time clock IRQ9 Microsoft ACPI-Compliant System IRQ10 Available IRQ11 Available IRQ12 PS/2 Compatible Mouse IRQ13 Numeric data processor IRQ14 Primary IDE IRQ15 Secondary IDE MIO-2261 User Manual Data Modul AG - www.data-modul.com... - Page 82 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2012 Data Modul AG - www.data-modul.com...
- Page 83 WS9 8UG - United Kingdom Phone: +44-1922-457358 Data MoDul Inc. / uSa 275 Marcus Blvd, Unit K Hauppauge, NY 11788 - USA Phone: +1-631-951-0800 Data MoDul aG | landsberger Str. 322 | 80687 Munich | tel. +49-89-56017-0 | Fax +49-89-56017-119 | www.data-modul.com...
