Page 1: User Manual
User Manual Version : January 2013... -
Page 2: Table Of Contents
Serial Port Connector (COM1 & COM2 ) ..................25 1.7.7 Digital I/O Connector (JDIO) ......................25 1.7.8 SATA Data Connector (SATA1&2) ....................26 1.7.9 SATA Power Connector (SATAPWR1)..................26 1.7.10 Mic-In & Line-In Connector (JAUDIO1) ..................27 1.7.11 USB 3&4 Connector (USB2)...................... 27 Data Modul AG - www.data-modul.com... - Page 3 Security Settings........................54 2.2.4.2 Boot Setting Configuration..................... 55 2.2.5 Exit..............................56 2.2.5.1 Save Changes and Exit ......................57 2.2.5.2 Discard Changes and Exit ..................... 57 2.2.5.3 Discard Changes ........................58 2.2.5.4 Load Setup Defaults ......................58 ENX-PNV Data Modul AG - www.data-modul.com...
-
Page 4: Safety Information
The symbol of the crossed out wheeled bin indicates that the product (electrical and electronic equipment) should not be placed in municipal waste. Check local regulations for disposal of electronic products. Data Modul AG - www.data-modul.com... -
Page 5: Safety Declaration
CAUTION: Information to prevent damage to the components when trying to complete a task. IMPORTANT: Instructions that you MUST follow to complete a task. NOTE: Tips and additional information to help you complete a task. ENX-PNV Data Modul AG - www.data-modul.com... -
Page 6: Packing List
ENX-PNV Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x ENX-PNV Nano-ITX Motherboard 1 x CD-ROM contains the followings: • User’s Manual in PDF file • Drivers 1 x Cable Kit •... -
Page 7: Revision History
User’s Manual Revision History Revision Revision History Date V 1.0 First version for PCB 1.1 March, 2010 ENX-PNV Data Modul AG - www.data-modul.com... -
Page 8: Specifications Summary
Realtek ALC888, 5.1 + 2 CH HD Audio Audio Interface Line out (jack) , Mic. In & Line in (pin header) Ethernet LAN1 Realtek RTL 8111C Gigabit LAN * Specifications are subject to change without notice. Data Modul AG - www.data-modul.com... -
Page 9: Block Diagram
User’s Manual Block Diagram ENX-PNV Data Modul AG - www.data-modul.com... - Page 10 ENX-PNV This chapter describes the main board features and the new technologies it supports. 1 1 1 1 1 1 1 1 Product Product introduction introduction Data Modul AG - www.data-modul.com...
-
Page 11: Before You Proceed
Before you install or remove any component, ensure that the ATX power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, and/or components. ENX-PNV Data Modul AG - www.data-modul.com... -
Page 12: Motherboard Overview
Place four (4) screws into the holes indicated by circles to secure the motherboard to the chassis. Do not over tighten the screws! Doing so can damage the motherboard. Place this side towards the rear of the chassis. Data Modul AG - www.data-modul.com... -
Page 13: Motherboard Layout
User’s Manual 1.3 Motherboard Layout ENX-PNV Data Modul AG - www.data-modul.com... -
Page 14: Layout Content List
SATA Data Connector * 2 7P Male connector SATAPWR1 SATA Power Connector 2 x 2 female box header JAUDIO1 Mic-In & Line-In Connector 5 x 2 header, pitch 2.00mm USB2 USB 3&4 Connector 5 x 2 header, pitch 2.00mm Data Modul AG - www.data-modul.com... -
Page 15: System Memory
GB DDR2 memory modules. This motherboard does not support memory modules FSB less than 667MHz.Make sure that the memory frequency matches the CPU FSB (Front Side Bus). Refer to the Memory frequency/CPU FSB synchronization table. ENX-PNV Data Modul AG - www.data-modul.com... -
Page 16: Installing A Ddr2 Dimm
A DDR2 DIMM is keyed with a notch so that it fits in only one direction. DO NOT force a DIMM into a socket to avoid damaging the DIMM. The DDR2 DIMM sockets do not support DDR/DDR3 DIMMs. DO NOT install DDR/DDR3 DIMMs to the DDR2 DIMM socket. Data Modul AG - www.data-modul.com... -
Page 17: Removing A Ddr2 Dimm
1. Press the two ejector tabs on the slot outward simultaneously, and then pull out the DIMM module. Support the DIMM lightly with your fingers when pressing the ejector tabs. The DIMM might get damaged when it flips out with extra force. ENX-PNV Data Modul AG - www.data-modul.com... -
Page 18: Expansion Slots
1. Turn on the system and change the necessary BIOS settings, if any. See Chapter 2 for information on BIOS setup. 2. Assign an IRQ to the card if needed. Refer to the tables on the next page. 3. Install the software drivers for the expansion card. Data Modul AG - www.data-modul.com... -
Page 19: Minipci Express Slot
6. Hold down the <Del> key during the boot process and enter BIOS setup to re-enter data. Except when clearing the CMOS, never remove the cap on the CLRTC jumper default position. Removing the cap will cause system boot failure! ENX-PNV Data Modul AG - www.data-modul.com... -
Page 20: Com1, Com2 Ri/+5V/+12V Select (Jcompwr1, Jcompwr2)
ENX-PNV Normal (Default) Clear CMOS 1.6.2 COM1, COM2 RI/+5V/+12V Select (JCOMPWR1, JCOMPWR2) RI (Default) +12V Data Modul AG - www.data-modul.com... -
Page 21: Connectors
8-channel configuration, the function of this port becomes Front Speaker Out. DCIN1 12V DC-In Power Jack This power jack is connecting for 12V AC/DC pin 2.5mm power adapter . 12V 40W above is recommended . ENX-PNV Data Modul AG - www.data-modul.com... -
Page 22: Cpu Fan Connector (Fan1)
Insufficient air flow inside the system may damage the motherboard components. This is not a jumper! DO NOT place a jumper cap on the fan connector. 1.7.3 LVDS Connector (JLVDS) This motherboard supports 18-bit single channel LVDS panel. Data Modul AG - www.data-modul.com... -
Page 23: Lcd Inverter Connector (Jbkl)
Signal Description For inverter with adjustable Backlight function, it is possible to control the LCD brightness through the VR signal. Vadj=0.75V ~ 4.25V (Recommended: 4.7K , > 1/16W) ENBKL LCD backlight ON/OFF control signal ENX-PNV Data Modul AG - www.data-modul.com... -
Page 24: System Panel Connector (F_Panel)
The IDE LED lights up or flashes when data is read from or written to the HDD. Reset Button (2-pin RESET) This 2-pin connector is for the chassis-mounted reset button for a system reboot without turning off the system power. Data Modul AG - www.data-modul.com... -
Page 25: Serial Port Connector (Com1 & Com2 )
These 2 connectors are for serial (COM) port. Connect the serial port module cable to this connector, and then install the module to a slot opening at the back of the system chassis. COM 1&2 1.7.7 Digital I/O Connector (JDIO) This connector supports 8-bit General purpose I/O function. ENX-PNV Data Modul AG - www.data-modul.com... -
Page 26: Sata Data Connector (Sata1&2)
Find the proper orientation and push down firmly until the connector completely fits. This 2x2P connector is for SATA power supply, plugging-in an ATX 2x2P power cable from PSU will damage this motherboard . Data Modul AG - www.data-modul.com... -
Page 27: Mic-In & Line-In Connector (Jaudio1)
This USB connector complies with USB 2.0 specification that supports up to 480 Mbps connection speed. Never connect a 1394 cable to the USB connectors. Doing so will damage the motherboard! The USB module is purchased separately. ENX-PNV Data Modul AG - www.data-modul.com... - Page 28 This chapter tells how to change the system settings through the BIOS setup menus. Detailed descriptions of the BIOS parameters are also provided. 2 2 2 2 2 2 2 2 BIOS setup BIOS setup Data Modul AG - www.data-modul.com...
-
Page 29: Bios Setup Program
The BIOS setup screens shown in this section are for reference purposes only, and may not exactly match what you see on your screen. Visit the system builder’s website to download the latest BIOS file for this motherboard ENX-PNV Data Modul AG - www.data-modul.com... -
Page 30: Legend Box
While moving around through the Setup program, note that explanations appear in the Item Specific Help window located to the right of each menu. This window displays the help text for the currently highlighted field. Data Modul AG - www.data-modul.com... -
Page 31: Bios Menu Screen
To access the menu items, press the up/down/right/left arrow key on the keyboard until the desired item is highlighted, then press [Enter] to open the specific menu. ENX-PNV Data Modul AG - www.data-modul.com... -
Page 32: Main
2.2.1 Main Use this menu for basic system configurations, such as time, date etc. 2.2.1.1 System Time The time format is <Hour> <Minute> <Second>. 2.2.1.2 System Date The date format is <Day>, <Month> <Date> <Year>. Data Modul AG - www.data-modul.com... -
Page 33: Primary Ide Master
SATA device type. Select CD/DVD if you are specifically configuring a CD-ROM/DVD-ROM drive. Select ARMD (ATAPI Removable Media Device) if your device is either a ZIP, LS-120, or MO drive. Configuration options: [Not Installed] [Auto] [CD/DVD] [ARMD] ENX-PNV Data Modul AG - www.data-modul.com... - Page 34 [UDMA5] [UDMA6]. Only [Auto] is showed if no SATA device is installed in the system. S.M.A.R.T. [Auto] Set the Smart Monitoring, Analysis, and Reporting Technology. Configuration options: [Auto] [Disabled] [Enabled] 32Bit Data Transfer [Enabled] Enables or disables 32-bit data transfer. Configuration options: [Disabled] [Enabled] Data Modul AG - www.data-modul.com...
-
Page 35: Ide Configuration
User’s Manual 2.2.1.4 IDE Configuration ATA/IDE Configuration [Enhanced] Allows you to set SATA Configuration function. Configuration options: [Compatible] [Enhanced] Configure SATA as [IDE] Allows you to set SATA as function[IDE] or [AHCI] ENX-PNV Data Modul AG - www.data-modul.com... -
Page 36: Ahci Setting
ENX-PNV 2.2.1.5 AHCI Setting AHCI Port0 & Port1 SATA AHCI functions for setting are [Auto] [Not Detected] further function settings after SATA devices detected are: AHCI Port0 [Disabled] [Enabled] AHCI Port1 [Disabled] [Enabled] Data Modul AG - www.data-modul.com... -
Page 37: System Information
This menu gives you an overview of the general system specifications. The BIOS automatically detects the items in this menu. AMI BIOS Display the auto-detected BIOS information. Processor Display the auto-detected CPU specification. System Memory Display the auto-detected system memory. ENX-PNV Data Modul AG - www.data-modul.com... -
Page 38: Advanced
The Advanced menu items allow you to change the settings for the CPU and other system devices. Take caution when changing the settings of the Advanced menu items. Incorrect field values can cause the system to malfunction. Data Modul AG - www.data-modul.com... -
Page 39: Cpu Configuration
HTT requires only that the operating system supports multiple processors. It is recommended that you leave it at the default setting of Disabled. Only enable it if you intend to use Hyper-Threading Technology with an operating system that supports it. ENX-PNV Data Modul AG - www.data-modul.com... -
Page 40: Chipset
It is recommended that you leave it at the default setting of Auto. Only Atom D510 CPU supports 800MHz DDR2 SO-DIMM Configure DRAM Timing by SPD [Enable] Allows you to set DRAM timing , Configuration options: [Enable] [Disable] Data Modul AG - www.data-modul.com... - Page 41 - Flat Panel Type , Set for panel resolution , Configuration options: Type 1 640x480 Type 2 800x600 Type 3 1024x768 Type 4 1280x768 Type 5 1280x800 Type 6 1280x600 - Spread Spectrum Clock , Set for panel resolution , Configuration options: [Disable] [Enabled] ENX-PNV Data Modul AG - www.data-modul.com...
-
Page 42: Onboard Device Configuration
Serial Port1 Address [3F8/IRQ4] Allow you to select the Serial Port1 base address. Configuration options: [Disabled] [3F8/IRQ4] [3E8/IRQ4] [2E8/IRQ3]. Serial Port2 Address [2F8/IRQ3] Allow you to select the Serial Port1 base address. Configuration options: [Disabled] [2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]. Data Modul AG - www.data-modul.com... -
Page 43: Usb Configuration
USB controller legacy mode is enabled. If no USB device is detected, the legacy USB support is disabled. Configuration options: [Disabled] [Enabled] [Auto] BIOS EHCI Hand-Off [Enabled] Allows you to enable support for operating systems without an EHCI hands off feature. Configuration options: [Disabled] [Enabled]. ENX-PNV Data Modul AG - www.data-modul.com... -
Page 44: Trusted Computing (Optional)
<Enter> to display the configuration options. TCG/TPM SUPPORT [YES] Allows you to enable or disable TCG/TPM 1.2 support in BIOS. Configuration options: [No] [Yes]. The following items show when you set TCG/TPM SUPPORT option to [YES]. Data Modul AG - www.data-modul.com... -
Page 45: Pci Pnp
PCI Latency Timer [64] Allow the PCI Latency Timer to be adjusted. This option sets the latency of all PCI devices on the PCI bus. Configuration options: [32] [64] [96] [128] [160] [192] [224] [248] ENX-PNV Data Modul AG - www.data-modul.com... - Page 46 This setting allows the specified IRQ to be used by a PCI/PnP IRQ4 device. This is the default setting. IRQ5 IRQ7 IRQ9 Reserved This setting allows the specified IRQ to be used by a legacy ISA IRQ10 device. IRQ11 IRQ14 IRQ15 Data Modul AG - www.data-modul.com...
- Page 47 DMA Channel 5 DMA Channel 6 Reserved This setting allows the specified DMA to be used by a legacy DMA Channel 7 ISA device. Reserved Memory Size [Disabled] Configuration options: [Disabled] [16K] [32K] [64K] ENX-PNV Data Modul AG - www.data-modul.com...
-
Page 48: Power
Determine whether to invoke VGA BIOS post on S3/STR Resume. Configuration options: [Yes] [No] 2.2.3.3 ACPI Version Features Allows you to add more tables for advanced Advanced Configuration and Power Interface (ACPI) 2.0 specifications. Configuration options: [ACPI V1.0], [ACPI V2.0], [ACPI V3.0]. Data Modul AG - www.data-modul.com... -
Page 49: Acpi Apic Support
<Arrow> keys to select an item. Use the <Plus> and <Minus> keys to change the value of the selected option. The settings are described on the following pages. The screen is shown below. Power Button Mode [On/Off] The option: [On/Off] [Suspend]. Resume On Ring The option: [Disabled] [Enabled]. ENX-PNV Data Modul AG - www.data-modul.com... - Page 50 When set to [Off], the system goes into off state after an AC power loss. When set to [On], the system goes on after an AC power loss. Configuration options: [Off] [On] [Previous State]. Watchdog Timer (SECOND) Allows you to set time-out of the Watchdog counter. Data Modul AG - www.data-modul.com...
-
Page 51: Hardware Health Configuration
(RPM). If the fan is not connected to the motherboard, the field shows N/A. +12VIN / +5VIN / Vcore / VCC / VBAT [xxxx Voltage] The onboard hardware monitor automatically detects the voltage output through the onboard voltage regulators. ENX-PNV Data Modul AG - www.data-modul.com... - Page 52 [Optimal Mode]：Keeps a balance between CPU temperature and fan speed. [Silent Mode] ：Keeps the system at a lower acoustic than Optimized mode with lower fan speed. [Performance Mode]：Keeps the CPU at a lower temperature than Optimized mode with faster fan speed. Data Modul AG - www.data-modul.com...
-
Page 53: Boot
User’s Manual 2.2.4 Boot The Boot menu items allow you to change the system boot options. Select an item then press <Enter> to display the sub-menu. ENX-PNV Data Modul AG - www.data-modul.com... -
Page 54: Security Settings
After you have set a supervisor password, the other items appear to allow you to change other security settings. If you forget your BIOS password, you can clear it by erasing the CMOS Real Time Clock (RTC) RAM. Data Modul AG - www.data-modul.com... -
Page 55: Boot Setting Configuration
AddOn ROM Display Mode [Force BIOS] Set the display mode for ROM option. Configuration options: [Force BIOS] [Keep Current] Bootup Num-Lock [On] Allows you to select the power-on state for the NumLock. Configuration options: [Off] [On] ENX-PNV Data Modul AG - www.data-modul.com... -
Page 56: Exit
BIOS items. Press <ESC> does not immediately exit this menu. Select on of the options from this menu or <F10> from the legend bar to exit. Data Modul AG - www.data-modul.com... -
Page 57: Save Changes And Exit
Select this option only if you do not want to save the changes that you made to the setup program. If you made changes to fields other than System Date, System time, and Password, the BIOS asks for a confirmation before exiting. ENX-PNV Data Modul AG - www.data-modul.com... -
Page 58: Discard Changes
Setup menus. When you select this option or if you press <F5>, a confirmation window appears. Select [OK] to load optimal default values. Select [Save Change and Exit] or make other changes before saving the values to the non-volatile RAM. Data Modul AG - www.data-modul.com... - Page 59 WS9 8UG - United Kingdom Phone: +44-1922-457358 Data MoDul Inc. / uSa 275 Marcus Blvd, Unit K Hauppauge, NY 11788 - USA Phone: +1-631-951-0800 Data MoDul aG | landsberger Str. 322 | 80687 Munich | tel. +49-89-56017-0 | Fax +49-89-56017-119 | www.data-modul.com...
