CN10
Part Number
Footprint
Description
Pin
1
2
3
4
5
6
7
8
9
CN11
Part Number
Footprint
Description
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Internal USB
1653005260
HD_5x2P_79_N10
PIN HEADER 2*5P 180D(M) 2.0 mm SMD IDIOT-PROOF
Pin Name
+5 V
+5 V
A_D-
B_D-
A_D+
B_D+
GND
GND
GND
COM1/COM2
1653003720
HD_10x2P_79_RA
Pin Name
DCD1#
DSR1#
RXD1
RTS1#
TXD1
CTS1#
DTR1#
RI1#
GND
GND
DCD2#
DSR2#
RXD2
RTS2#
TXD2
CTS2#
DTR2#
RI2#
GND
GND
53
