The sample programs demonstrate how to incorporate SUSI into your program. The

sample programs run in graphics mode in Windows® 7 are described in the subsec-

tions below.

Windows Graphics Mode

Each demo application contains an executable file SusiDemo.exe, a shared library

Susi.dll and source code within the release package.

SusiDemo.exe is an executable file and it requires the shared library, Susi.dll, to

demonstrate the SUSI functions. The source code of SusiDemo.exe must be com-

piled under Microsoft Visual C++ 6.0 on Windows 7. Developers must add the header

file Susi.h and library Susi.lib to their own projects when they want to develop some-

thing with SUSI.

SusiDemo.exe

The SusiDemo.exe test application is an application which uses all functions of the

SUSI Library. It has five major function blocks: Watchdog, GPIO, SMBus, I

C and

VGA control. The following screen shot appears when you execute SusiDemo.exe.

You can click function tabs to select test functions respectively. Some function tabs

will not show on the test application if your platform does not support such functions.

For a complete support list, please refer to Appendix A. We describe the steps to test

all functions of this application.

GPIO
