Data Modul MIO-2261 User Manual page 62

CN8
Part Number
Footprint
Description
Pin
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
CN9
Part Number
Footprint
Description
Pin
1
2
3
4
MIO-2261 User Manual
Data Modul AG - www.data-modul.com
Mini PCIE
00A00000660
MINIPCIE_HALF_PICO2600
Pin Name
GND
+1.5 V
GND
SMB_CLK
PETn0
SMB_DAT
PETp0
GND
GND
USB D-
GND
USB D+
+3.3 VSB
GND
+3.3 VSB
NC
GND
NC
NC
NC
NC
+1.5 V
NC
GND
NC
+3.3 VSB
External USB
1654009513
USB_8P_UB1112C-8FDE-4F
Pin Name
+5 V
D-
D+
GND
