  • Page 1 Specification PCM-3362 Data Modul AG - www.data-modul.com...

  • Page 2: Packing List

    Packing List Before you begin installing your card, please make sure that the following materials have been shipped: 1 x PCM-3362 SBC 1 x SATA data cable (p/n: 1700071000) 1 x SATA power cable (p/n: 1703150102) 1 x Keyboard/Mouse cable...
  • Page 3 Caution! There is a danger of a new battery exploding if it is incorrectly installed. Do not attempt to recharge, force open, or heat the battery. Replace the battery only with the same or equivalent type recommended by the man- flatterer. Discard used batteries according to the manufacturer's instruc- tions. PCM-3362 User Manual...

  • Page 4: Table Of Contents

    2.17 ATX Power in connector (CN23)............. 15 2.18 Power Connectors (CN24) ..............15 2.19 I2C Bus connector (CN25) ..............15 2.20 -12 V & -5 V power connector (CN26) ........... 15 2.21 Watchdog timer configuration ..............15 PCM-3362 User Manual...
  • Page 5 Figure 3.26South Bridge Configuration ........34 Exit Option ....................35 Figure 3.27Exit Option..............35 3.8.1 Save Changes and Exit .............. 35 3.8.2 Discard Changes and Exit ............36 3.8.3 Load Optimal Defaults ..............36 3.8.4 Load Fail-Safe Defaults .............. 36 PCM-3362 User Manual...
  • Page 6 ......69 Board Mechanical Drawings ..............70 Figure C.1 PCM-3362 Mechanical Drawing (Component Side). 70 Figure C.2 PCM-3362 Mechanical Drawing (Solder Side) ..71 Heatsink Mechanical Drawings ............... 72 Figure C.3 PCM-3362N Heatsink Mechanical Drawing ..... 72 Figure C.4 PCM-3362Z/Z2 Heatsink Mech Dwg, wide temp..72 Optional Heat spreader Mechanical Drawings........
  • Page 7 Appendix D Watchdog Timer and GPIO sample code............ 75 Watchdog Timer sample code ..............76 GPIO sample code.................. 77 PCM-3362 User Manual viii...

  • Page 8: Chapter 1 General Information

    Chapter General Information This chapter gives background information on the PCM-3362. Sections include: Introduction Features Specifications Board layout and dimensions...

  • Page 9: Introduction

    Supported operating systems include Windows 7, Windows XP, XP Embedded, Win- dows CE, and Linux. PCM-3362 also offers drivers and APIs for application develop- ment including I C, GPIO, watchdog timer, hardware monitor, panel backlight on/off, and brightness control.

  • Page 10: Vga/Lvds Interface

    82567V 1.3.4 OS support This board supports Win7,Win XP, Win CE and Win XPe. For further information about OS support in your PCM-3362, visit the following Advantech web resource: www.advantech.com or please contact your technical sup- port center. 1.3.5 Mechanical and Environmental Dimensions: 96 x 90 mm (3.8"...

  • Page 11: Board Layout: Dimensions

    Operating temperature: 0 ~ 60°C (32 ~ 140°F) (operation humidity: 40°C @ 85% RH Non-Condensing) Weight: 0.85 kg (reference weight of total package) Board layout: dimensions Figure 1.1 Board layout: Dimensions (Component Side) PCM-3362 User Manual...

  • Page 12: Figure 1.2 Board Layout: Dimensions (Solder Side)

    Figure 1.2 Board layout: Dimensions (Solder Side) PCM-3362 User Manual...
  • Page 13 PCM-3362 User Manual...

  • Page 14: Chapter 2 Hardware Installation

    Chapter Hardware Installation...

  • Page 15: Jumpers

    Be sure to read all safety precautions before you begin the installation procedure. Jumpers The PCM-3362 has a number of jumpers that allow you to configure your system to suit your application. The table below lists the functions of the various jumpers.

  • Page 16: Locating Connectors & Block Diagram

    Locating Connectors & block diagram Figure 2.1 Connectors (component side) Figure 2.2 Connectors (solder side) PCM-3362 User Manual...

  • Page 17: Setting Jumpers

    To “close” a jumper, you connect the pins with the clip. To “open” a jumper, you remove the clip. Sometimes a jumper will have three pins, labeled 1, 2 and 3. In this case you would connect either pins 1 and 2, or 2 and 3. PCM-3362 User Manual...

  • Page 18: Clear Cmos (Jp1)

    2.4.1 Clear CMOS (JP1) The PCM-3362 single board computer contains a jumper that can erase CMOS data and reset the system BIOS information. Normally this jumper should be set with pins 1-2 closed. If you want to reset the CMOS data, set CMOS1 to 2-3 closed for just a few seconds, and then move the jumper back to 1-2 closed.

  • Page 19: Com3 Rs422/Rs485 Select (Jp3)

    They combine an integrated ATA Controller in a multi-chip pack- age. These products are ideal for industrial grade solid state mass storage applica- tions offering new and expanded functionality while enabling cost effective designs. PCM-3362 User Manual...

  • Page 20: High Definition Audio Interface (Cn1)

    CRT display connector CN8 are detailed in Appendix A. 2.8.2 LVDS connector (CN6) The PCM-3362 uses the Intel Atom N450 that supports single -channel 18-bit LVDS panel up to WXGA 1366 x 768 UXGA panel resolution. 2.8.3 Panel Inverter Power (CN7) The LCD inverter is connected to CN7 via a 5-pin connector to provide +5 V/+12 V power to the LCD display.

  • Page 21: Buzzer Connector (Cn13)

    2.14 Giga LAN Connector (CN18) PCM-3362 uses the Intel? 82567V Gigabit LAN chips are linked to dedicated PCIe x1 lanes. PCM-3362 provide high throughputs for heavy loading networking environ- ment. LAN connections are made via two internal 10-pin box header.

  • Page 22: Gpio Connector (Cn21)

    2.18 Power Connectors (CN24) Supplies main power +5 V to the PCM-3362, and to devices that require +12 V. 2.19 I2C Bus connector (CN25) PCM-3362 provides I2C Bus connector for customer connection to I2C protocol embedded device.
  • Page 23 PCM-3362 User Manual...

  • Page 24: Chapter 3 Ami Bios Setup

    Chapter AMI BIOS Setup...

  • Page 25: Entering Setup

    AMIBIOS has been integrated into many motherboards for over a decade. With the AMIBIOS Setup program, you can modify BIOS settings and control the various sys- tem features. This chapter describes the basic navigation of the PCM-3362 BIOS setup screens.

  • Page 26: System Time / System Date

    MM/DD/YY format. The time must be entered in HH:MM:SS format. Advanced BIOS Features Setup Select the Advanced tab from the PCM-3362 setup screen to enter the Advanced BIOS Setup screen. You can select any of the items in the left frame of the screen, such as CPU Configuration, to go to the sub menu for that item.

  • Page 27: Cpu Configuration

    This item allows you to enable or disable Intel® Hyper Threading technology. Intel® SpeedStep tech When set to disabled, the CPU runs at its default speed, when set to enabled, the CPU speed is controlled by the operating system. PCM-3362 User Manual...

  • Page 28: Ide Configuration

    Hard Disk Write Protect Disable/Enable device write protection. This will be effective only if device is accessed through BIOS. IDE Detect Time Out (Sec) This item allows you to select the time out value for detecting ATA/ATAPI device(s). PCM-3362 User Manual...

  • Page 29: Super I/O Configuration

    Auto Direction Control Sel This item allows you to enable or disable auto flow control function. 3.3.4 Hardware Health Configuration Figure 3.7 Hardware health configuration H/W Health Function This item allows you to control H/W monitor of showing. PCM-3362 User Manual...

  • Page 30: Acpi Settings

    Figure 3.8 ACPI Settings 3.3.5.1 General ACPI Configuration Figure 3.9 General ACPI Configuration Suspend mode Select the ACPI state used for system suspend. Report Video on S3 Resume This item allows you to invoke VA BIOS POST on S3/STR resume. PCM-3362 User Manual...

  • Page 31: Figure 3.10Advanced Acpi Configuration

    Include APIC table pointer to RSDT pointer list. AMI OEMB table Include OEMB table pointer to R(x)SDT pointer lists. Headless mode Enable / Disable Headless operation mode through ACPI. 3.3.5.3 Chipset ACPI Configuration Figure 3.11 Chipset ACPI Configuration PCM-3362 User Manual...

  • Page 32: Ahci Configuration

    High Performance Event Timer Enable/Disable High performance Event timer. 3.3.6 AHCI Configuration Figure 3.12 Advanced ACPI Configuration AHCI Ports0 While entering setup, BIOS auto detects the presence of IDE devices. This displays the status of auto detection of IDE device. PCM-3362 User Manual...

  • Page 33: Apm Configuration

    Resume On Ring Enable / Disable RI to generate a wake event. Resume On PME# Enable / Disable PME to generate a wake event. Resume On RTC Alarm Enable / Disable RTC to generate a wake event. PCM-3362 User Manual...

  • Page 34: Event Log Configuration

    Mark all events as read Mark all unread events as read. Clear Event Log Discard all events in the event Log. 3.3.9 MPS Configuration Figure 3.15 South Bridge ACPI Configuration MPS Revision This item allows you to select MPS reversion. PCM-3362 User Manual...

  • Page 35: Smbios Configuration

    Figure 3.17 South Bridge ACPI Configuration Legacy USB Support Enables support for legacy USB. Auto option disables legacy support if no USB devices are connected. USB 2.0 Controller Mode This item allows you to select HiSpeed(480Mbps) or FullSpeed (12Mpbs). PCM-3362 User Manual...

  • Page 36: Advanced Pci/Pnp Settings

    FDD (Ex. ZIP drive). Advanced PCI/PnP Settings Select the PCI/PnP tab from the PCM-3362 setup screen to enter the Plug and Play BIOS Setup screen. You can display a Plug and Play BIOS Setup option by highlight- ing it using the <Arrow> keys. All Plug and Play BIOS Setup options are described in this section.

  • Page 37: Figure 3.19Pci/Pnp Setup (Top)

    When set to Available will specified DMA is available to be used by PCI/PnP devices. When set to Reserved will specified DMA will Reserved for use by legacy ISA devices. Reserved Memory Size This item allows you to reserved size of memory block for legacy ISA device. PCM-3362 User Manual...

  • Page 38: Boot Settings

    Quiet Boot If this option is set to Disabled, the BIOS displays normal POST messages. If Enabled, an OEM Logo is shown instead of POST messages. AddOn ROM Display Mode Set display mode for option ROM. PCM-3362 User Manual...

  • Page 39: Security Setup

    Security Setup Figure 3.22 Password Configuration Select Security Setup from the PCM-3362 Setup main BIOS setup menu. All Security Setup options, such as password protection and virus protection are described in this section. To access the sub menu for the following items, select the item and press <Enter>:...

  • Page 40: Advanced Chipset Settings

    This item allows you to enables or disables detect by DRAM SPD. Memory Hole This item allows you to free 15MB-16MB of memory size for some ISA devices. Internal Graphics Mode Select: Select the amount of system memory used by the Internal graphics device. PCM-3362 User Manual...

  • Page 41: South Bridge Chipset Configuration

    Flat Panel Type This item allows you to select which panel resolution you wants. Spread Spectrum Clock This item allows you to enables or disables spread spectrum clock. 3.7.2 South Bridge Chipset Configuration Figure 3.26 South Bridge Configuration PCM-3362 User Manual...

  • Page 42: Exit Option

    BIOS setup and reboot the computer so the new system configuration parameters can take effect. Select Exit Saving Changes from the Exit menu and press <Enter>. The following message appears: Save Configuration Changes and Exit Now? [Ok] [Cancel] Select Ok or cancel. PCM-3362 User Manual...

  • Page 43: Discard Changes And Exit

    3.8.3 Load Optimal Defaults The PCM-3362 automatically configures all setup items to optimal settings when you select this option. Optimal Defaults are designed for maximum system performance, but may not work best for all computer applications. In particular, do not use the Opti- mal Defaults if your computer is experiencing system configuration problems.

  • Page 44: Chapter 4 Software Introduction & Installation

    Chapter Software Introduction & Installation...

  • Page 45: S/W Introduction

    CE. This user’s manual describes some sample programs and the API in SUSI. The hardware functions currently supported by SUSI can be grouped into a few catego- ries including Watchdog, I C, SMBus, GPIO, and VGA control. Each category of API in SUSI is briefly described below. PCM-3362 User Manual...

  • Page 46: Software Apis

    4.3.2 Software APIs PCM-3362 supports software APIs including GPIO, I C, backlight on/off, Brightness control, watchdog, Hardware Monitor, and Power Saving. 4.3.2.1 The GPIO API General Purpose Input/Output is a flexible parallel interface that allows a variety of custom connections. It allows users to monitor the level of signal input or set the out- put status to switch on/off a device.

  • Page 47: Susi Utilities

    It will diagnose the hardware status, and then send an e-mail to a designated administrator. The eSOS also provides remote connection: Telnet server and FTP server, allowing the administrator to rescue the system. Note! eSOS Utility support on PCM-3362 is required to have BIOS modifica- tion. 4.3.4 SUSI Installation SUSI supports many different operating systems.
  • Page 48 If you want to run the console-based demo, add following lines: Watchdog.exe $(_FLATRELEASEDIR)\Watchdog.exe NK S GPIO.exe $(_FLATRELEASEDIR)\GPIO.exe NK S SMBUS.exe $(_FLATRELEASEDIR)\SMBUS.exe NK S Place the three files into any files directory. Build your new Windows CE operating system. PCM-3362 User Manual...

  • Page 49: Susi Sample Programs

    For a complete support list, please refer to Appendix A. We describe the steps to test all functions of this application. GPIO PCM-3362 User Manual...
  • Page 50 Key in the value in (R/W) Result field from ‘0x01’ to ‘0x0F’ to write the value of the output pin. The pin numbers are ordered bitwise, i.e. bit 0 stands for GPIO 0, bit 1 stands for GPIO 1, etc. For example, if you want to set pin 0 PCM-3362 User Manual...
  • Page 51 Access multiple bytes mode must be written in decimal. You can test the functional- ities of the watchdog as follows: Read a byte PCM-3362 User Manual...
  • Page 52 Key in all the desired data in the Result field in hexadecimal format, divided by commas, for example, 0x50,0x60,0x7A. – Click the WRITE SMBus DATA button and all of the data will be written to the device through the SMBus. PCM-3362 User Manual...
  • Page 53 DOG INFORMATION group box. It displays max timeout, min timeout, and timeout steps in milliseconds. For example, a 1~255 seconds watchdog will has 255000 max timeout, 1000 min timeout, and 1000 timeout steps. You can test the functionality of the watchdog as follows: PCM-3362 User Manual...
  • Page 54 If certain data values are not supported by the platform, the correspondent data field will be grayed-out with a value of 0. For More detail PCM-3362 software API user manual, please contact your dealer or Advantech AE. We also include these manuals in this CD.
  • Page 55 PCM-3362 User Manual...

  • Page 56: Chapter 5 Chipset Software Installation Utility

    Chapter Chipset Software Installation Utility...

  • Page 57: Before You Begin

    To facilitate the installation of the enhanced display drivers and utility software, read the instructions in this chapter carefully. The drivers for the PCM-3362 are located on the software installation CD. The driver in the folder of the driver CD will guide and link you to the utilities and drivers under a Windows system.

  • Page 58: Chapter 6 Integrated Graphic Device Setup

    Chapter Integrated Graphic Device Setup...

  • Page 59: Introduction

    Insert the driver CD into your system’s CD-ROM drive. You can see the driver folder items. Navigate to the "PCM-3362\02_ Graphic folder, and find folders including Win XP, Vista, and Win 7 and choose which of OS you would like to install.

  • Page 60: Chapter 7 Lan Configuration

    Chapter LAN Configuration...

  • Page 61: Introduction

    Introduction The PCM-3362 has Gigabit Ethernet LAN via dedicated PCI Express x 1 lanes (Intel 82567V), that offer bandwidth of up to 500 MB/sec, eliminating the bottleneck of net- work data flow and incorporating Gigabit Ethernet to operate at 1000Mbps.

  • Page 62: Appendix A Pin Assignments

    Appendix Pin Assignments This appendix contains informa- tion of a detailed or specialized nature. Sections include: Jumper and Connector Tables...

  • Page 63: Jumper And Connector Tables

    5V for +VLVDS_PANEL POWER Select (2-3) 3.3V for +VLVDS_PANEL POWER Select (Default) COM3 RS422/RS485 Select Part Number 1653003101 Footprint JH3X1V-2M Description PIN HEADER 3*1P 180D(M) 2.0mm DIP SQUARE W/O Pb Setting Function (1-2) RS485 (default) (2-3) RS422 PCI I/O Voltage Select PCM-3362 User Manual...
  • Page 64 1651000087 Footprint DDR-SODIMM-STD65 Description SKT DIMM 200P DDR2 H=6.5mm STD SMD WO/Pb LVDS Connector Part Number 1653910261 Footprint SPH10X2 Description *CONN. SMD 10*2P 180D(M)DF13-20DP-1.25V(91) HRS Pin Name Signal Type Signal Level LVDS0_z_D0+ LVDS LVDS0_z_D0- LVDS LVDS0_z_D1+ LVDS PCM-3362 User Manual...
  • Page 65 Wafer Box 1.25mm 12P 90D(M) SMD 85204-12001 Pin Name Signal Type Signal Level VGA_z_R +5 V VGA_z_G +5 V VGA_z_B +5 V +V5_CRT +5 V VGA_z_DDAT +5 V VGA_z_DCLK +5 V VGA_z_HS +5 V VGA_z_VS +5 V PCM-3362 User Manual...
  • Page 66 +5 V USB0_z_P- USB1_z_P- USB0_z_P+ USB1_z_P+ CN10 USB2/3 Part Number 1653003718 Footprint PH5x2P-SR2.00 Description PIN HEADER 5*2P 2.00mm 90D(M) NO.10 SMD Pin Name Signal Type Signal Level +V5_USB0 +5 V +V5_USB0 +5 V USB2_z_P- USB3_z_P- USB2_z_P+ USB3_z_P+ PCM-3362 User Manual...
  • Page 67 Signal Type Signal Level +V3.3 +3.3 V SB_z_SPKR CN15 SATA1 connector Part Number 1654000128 Footprint SATA-LD11071S02 Description Serial ATA 7P 90D(M) SMD 15u Reverse Pin Name Signal Type Signal Level SATA0_TX+ Analog SATA0_TX- Analog SATA0_RX- Analog SATA0_RX+ Analog PCM-3362 User Manual...
  • Page 68 COM1_RI# +5 V CN17 RS422/485 Connector Part Number 1655304120 Footprint WHL4H-2M_A Description WAFER BOX 2.0mm 4P 90D(M) DIP W/LOCK Pin Name Signal Type Signal Level RS422_RXD- +5 V RS422_RXD+ +5 V RS485_422_TXD+ +5 V RS485_422_TXD- +5 V PCM-3362 User Manual...
  • Page 69 CN20 PS2 Keyboard/Mouse Connector Part Number 1655306020 Footprint WHL6V-2M Description WAFER BOX 2.0mm 6P 180D(M) W/LOCK Pin Name Signal Type Signal Level KB_z_CLK# +5 V KB_z_DAT# +5 V MS_z_CLK# +5 V +V5_KB +5 V MS_z_DAT# +5 V PCM-3362 User Manual...
  • Page 70 +5 V PWR_PSON# CN24 Power In Connector Part Number 1655308120 Footprint WHL8H-2M Description Wafer Box 2.0mm 8P 90D Male W/Lock Pin Name Signal Type Signal Level +V5_ATX +5 V +V5_ATX +5 V +V5_ATX +5 V +V12 +12 V PCM-3362 User Manual...
  • Page 71 I2 C_DAT I2 C_CLK +V5_I2C CN26 -12V & -5V power connector Part Number 1653003101 Footprint HD_3x1P_79_D Description PIN HEADER 3*1P 180D(M) 2.0mm DIP SQUARE W/O Pb Pin Name Signal Type Signal Level -5 V -V12 -12 V PCM-3362 User Manual...

  • Page 72: Appendix B System Assignments

    Appendix System Assignments This appendix contains informa- tion of a detailed nature. Sections include: System I/O ports 1st MB memory map DMA channel assignments Interrupt assignments...

  • Page 73: System I/O Ports

    00000h - 9FFFFh Base memory * If Ethernet boot ROM is disabled (Ethernet ROM occupies about 16 KB) * E0000 - EFFFF is reserved for BIOS POST DMA channel assignments Table B.3: DMA channel assignments Channel Function Available PCM-3362 User Manual...

  • Page 74: Interrupt Assignments

    IRQ 5 Reserved (COM4) IRQ 6 IRQ 7 LPT1 IRQ 8 IRQ 9 Reserved (audio) IRQ 10 Reserved (COM3) IRQ 11 Reserved IRQ 12 PS/2 mouse IRQ 13 INT from co-processor IRQ 14 Primary IDE IRQ 15 Reserved PCM-3362 User Manual...
  • Page 75 PCM-3362 User Manual...

  • Page 76: Appendix C Mechanical Drawings

    Appendix Mechanical Drawings...

  • Page 77: Board Mechanical Drawings

    Board Mechanical Drawings Figure C.1 PCM-3362 Mechanical Drawing (Component Side) PCM-3362 User Manual...

  • Page 78: Figure C.2 Pcm-3362 Mechanical Drawing (Solder Side)

    Figure C.2 PCM-3362 Mechanical Drawing (Solder Side) PCM-3362 User Manual...

  • Page 79: Heatsink Mechanical Drawings

    Heatsink Mechanical Drawings Figure C.3 PCM-3362N Heatsink Mechanical Drawing Figure C.4 PCM-3362Z/Z2 Heatsink Mechanical Drawing for wide temperature version PCM-3362 User Manual...

  • Page 80: Optional Heat Spreader Mechanical Drawings

    Optional Heat spreader Mechanical Drawings Figure C.5 PCM-3362 optional Heatspreader Mechanical Drawing PCM-3362 User Manual...
  • Page 81 PCM-3362 User Manual...

  • Page 82: Code

    Appendix Watchdog Timer and GPIO sample code...

  • Page 83: Watchdog Timer Sample Code

    ;WDT timer time-out value ;bit[7:0]=0~255 ;==================================================== mov dx,SCH3114_IO + 66h mov al,01h out dx,al ;==================================================== ;bit[0] status bit R/W ;WD timeout occurred =1 ;WD timer counting = 0 ;==================================================== mov dx,SCH3114_IO + 68h mov al,01h out dx,al .exit PCM-3362 User Manual...

  • Page 84: Gpio Sample Code

    7 = gpio 7 , 0 => output pin; 1 => input pin mov ax,5E87h mov bh,01h mov cl,01h INT15 You will get GPIO default setting from bl ;=============================================================== ;=============================================================== Set GPIO Config ; Input: ax=5E87h bh=02h PCM-3362 User Manual...
  • Page 85 Set GPIO status ; Input: ax=5E87h bh=04h cl= n ; n means which group of GPIO you want to set bl= the n group of gpio status bit 0 = gpio 0 , 0 => Low; 1 => High PCM-3362 User Manual...
  • Page 86 1 = gpio 1 , 0 => Low; 1 => High ..bit 7 = gpio 7 , 0 => Low; 1 => High ; output: ax=5E78 ;function success, other value means function fail mov ax,5E87h mov bx,0400h mov cl,01 INT15 Set GPIO 0,2,4,6 Output Low ;=============================================================== PCM-3362 User Manual...
  • Page 87 www.advantech.com Please verify specifications before quoting. This guide is intended for reference purposes only. All product specifications are subject to change without notice. No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher.
  • Page 88 Adolfo Pérez Esquivel 3 Edificio Las Americas III Oficiana 40 28230 Parque Empresarial Madrid Las Rozas - Spain Tel.: +34-916 366 458 Data Modul Ltd. / UK 3 Brindley Place Birmingham B 12JB United Kingdom Tel.: +44-121-698-8641 Data Modul Inc. / USA...
