Summary of Contents for Data Modul IX57QM
-
Page 1: User Manual
User Manual Version March 201 Data Modul AG - www.data-modul.com... -
Page 2: Table Of Contents
Serial Port 2 Connector (COM2) ....................31 1.8.4 Front Panel Audio Connector (AAFP1) ..................32 1.8.5 CPU Fan Connector (CPU_FAN) ....................32 1.8.6 Chassis Fan Connector (CHA_FAN) ..................... 33 Data Modul AG - www.data-modul.com... - Page 3 SPI Connector (SPI1) ........................ 37 1.8.12 Digital Audio Connector (SPDIF_OUT1) ................... 37 1.8.13 Serial SATA Connector (SATA1, SATA2, SATA3, SATA4) ............38 1.8.14 USB 2.0 Connector (USB78, USB56) ..................39 IX57QM/IX55HM Data Modul AG - www.data-modul.com...
-
Page 4: Safety Information
The symbol of the crossed out wheeled bin indicates that the product (electrical and electronic equipment) should not be placed in municipal waste. Check local regulations for disposal of electronic products. Data Modul AG - www.data-modul.com... -
Page 5: Technical Support
CAUTION: Information to prevent damage to the components when trying to complete a task. IMPORTANT: Instructions that you MUST follow to complete a task. NOTE: Tips and additional information to help you complete a task. IX57QM/IX55HM Data Modul AG - www.data-modul.com... -
Page 6: Packing List
1 x SATA Cable Kit (SATA/Power) 1 x SATA DATA Cable 1 x I/O Shield 1 x Startup Manual 1 x CPU Cooler If any of the above items is damaged or missing, please contact your retailer. Data Modul AG - www.data-modul.com... -
Page 7: Revision History
User’s Manual Revision History Revision Revision History Date V 1.0 First release for PCB 1.00 September 3, 2010 IX57QM/IX55HM Data Modul AG - www.data-modul.com... -
Page 8: Specifications Summary
LVDS Support eDP Standard Version 1.1 Display Port TI Level Shift SN75DP139RGZR HDMI Audio Realtek ALC888 Audio Codec Audio Codec 5.1+2 CH. with two independent audio stream Mic in, Line in, Line out Audio Interface Data Modul AG - www.data-modul.com... - Page 9 0.88 lbs (0.4 Kg) Jumpers Label Function Note CLRTC Clear CMOS Normal * Clear CMOS Connectors Label Function Note AAFP1 Front Panel Audio Connector CHA_FAN Chassis Fan Connector CPU_FAN CPU Fan Connector SPDIF_OUT1 Digital Audio connector IX57QM/IX55HM Data Modul AG - www.data-modul.com...
- Page 10 F_PANEL1 System Panel Connector JDIO1 Digital I/O Connector JBKL1 LCD Inverter Connector SPI1 SPI Connector COM2 Serial Port Connector USB56, USB 2.0 Connector USB78 JLVDS1 LVDS Connector * Specifications are subject to change without notice. Data Modul AG - www.data-modul.com...
-
Page 11: Block Diagram
User’s Manual Block Diagram IX57QM/IX55HM Data Modul AG - www.data-modul.com... - Page 12 IX57QM/IX55HM This chapter describes the motherboard features and the new technologies it supports. Product Product introduction introduction Data Modul AG - www.data-modul.com...
-
Page 13: Production Introduction
Before you install or remove any component, ensure that the ATX power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, and/or components. IX57QM/IX55HM Data Modul AG - www.data-modul.com... -
Page 14: Motherboard Overview
Place four (4) screws into the holes indicated by circles to secure the motherboard to the chassis. Do not over tighten the screws! Doing so can damage the motherboard. Place this side towards the rear of the chassis Data Modul AG - www.data-modul.com... -
Page 15: Motherboard Layout
User’s Manual Motherboard Layout IX57QM/IX55HM Data Modul AG - www.data-modul.com... -
Page 16: Layout Content List
LAN_USB1 RJ-45 Ethernet connector x 1 29,30 USB connector x 2 LAN_USB2 RJ-45 Ethernet connector x 1 29,30 USB connector x 2 AUDIO Line-in port, Line-out port, 5.1 Channel Audio I/O (3 jacks) Microphone port, Data Modul AG - www.data-modul.com... - Page 17 Digital Audio connector 4 x 1 header, pitch 2.54mm SATA1,2,3,4 Serial ATA connectors 1,2,3,4 7-pin header USB5,6 USB 2.0 connector 5 x 2 header, pitch 2.0mm USB7,8 USB 2.0 connector 5 x 2 header, pitch 2.0mm IX57QM/IX55HM Data Modul AG - www.data-modul.com...
-
Page 18: Central Processing Unit (Cpu)
Install the motherboard to the chassis before you install the CPU Cooler assembly. Place the backplate on the rear side of the CPU so that the screw bolts stick through the mounting holes. Data Modul AG - www.data-modul.com... - Page 19 CPU fan connector. Please take off the protection cover at the bottom side of the Cooler first! Screwing Cooler to the screw bolts of the backplate. Tighten the screws until they stop. IX57QM/IX55HM Data Modul AG - www.data-modul.com...
- Page 20 Insufficient air flow inside the system may damage the motherboard components, and hardware monitoring errors can occur if you fail to plug this connector. These are not jumpers! DO NOT place jumper caps on the fan connectors. Data Modul AG - www.data-modul.com...
-
Page 21: System Memory
A DDR3 module has the same physical dimensions as a DDR2 SO-DIMM but has a 204-pin footprint compared to the 200-pin DDR2 DIMM. DDR3 SO-DIMMs are notched differently to prevent installation on a DDR2 SO-DIMM socket. The following figure illustrates the location of the sockets: IX57QM/IX55HM Data Modul AG - www.data-modul.com... -
Page 22: Memory Configurations
Due to chipset resource allocation, the system may detect less than 1 GB system memory when you installed one 1 GB DDR3 memory modules. Data Modul AG - www.data-modul.com... -
Page 23: Installing A Ddr3 So-Dimm
A DDR3 SO-DIMM is keyed with a notch so that it fits in only one direction. DO NOT force a SO-DIMM into a socket to avoid damaging the SO-DIMM. The DDR3 SO-DIMM sockets do not support DDR2 SO-DIMMs. DO NOT install DDR2 SO-DIMMs to the DDR3 SO-DIMM socket. IX57QM/IX55HM Data Modul AG - www.data-modul.com... -
Page 24: Removing A Ddr3 So-Dimm
Simultaneously press the retaining clips outward to unlock the SO-DIMM. Remove the SO-DIMM from the socket. Support the SO-DIMM lightly with your fingers when pressing the retaining clips. The SO-DIMM might get damaged when it flips out with extra force. Data Modul AG - www.data-modul.com... -
Page 25: Expansion Slots
Turn on the system and change the necessary BIOS settings if any. Assign an IRQ to the card if needed. Refer to the tables on the next page. Install the software drivers for the expansion card. IX57QM/IX55HM Data Modul AG - www.data-modul.com... -
Page 26: Standard Interrupt Assignments
IRQ holder for PCI streeing* IRQ holder for PCI streeing* IRQ holder for PCI streeing* PS/2 Compatible Mouse Port* Numeric Data Processor Primary IDE Channel Secondary IDE Channel * There IRQs are usually available for ISA or PCI device. Data Modul AG - www.data-modul.com... -
Page 27: Pci Express X16
Graphic card that can be installed on the PCI Express x16 slot. 1.6.5 Mini PCI Express x 1 This motherboard supports Mini PCI Express wireless LAN, and TV tuner device. IX57QM/IX55HM Data Modul AG - www.data-modul.com... -
Page 28: Jumpers
Hold down the <Del> key during the boot process and enter BIOS setup to re-enter data. Except when clearing the CMOS, never remove the cap on CLRTC jumper default position. Removing the cap will cause system boot failure! Normal (Default) Clear RTC Data Modul AG - www.data-modul.com... -
Page 29: Connectors
10/100/1000 Mbps connection to a Local Area Network (LAN) through a network hub. ACT / LINK LED SPEED LED Status Description Status Description No link 10Mbps connection Orange Linked ORANGE 100Mbps connection Blinking Data activity GREEN 1Gbps connection IX57QM/IX55HM Data Modul AG - www.data-modul.com... - Page 30 These four 4-pin Universal Serial Bus (USB) LAN2_USB34 ports are available for connecting USB 2.0 devices. VGA_COM1 VGA port D-sub15-pin VGA port connects to a VGA monitor. HDMI_DP HDMI connector High Definition Media Interface 19P connector Data Modul AG - www.data-modul.com...
-
Page 31: Atx Power Connector (Eatxpwr, Atx12V)
You must install a PSU with a higher power rating if you intend to install additional devices. 1.8.3 Serial Port 2 Connector (COM2) IX57QM/IX55HM Data Modul AG - www.data-modul.com... -
Page 32: Front Panel Audio Connector (Aafp1)
Insufficient air flow inside the system may damage the motherboard components, and hardware monitoring errors can occur if you fail to plug this connector. These are not jumpers! DO NOT place jumper caps on the fan connectors. Data Modul AG - www.data-modul.com... -
Page 33: Chassis Fan Connector (Cha_Fan)
Insufficient air flow inside the system may damage the motherboard components, and hardware monitoring errors can occur if you fail to plug this connector. These are not jumpers! DO NOT place jumper caps on the fan connectors. IX57QM/IX55HM Data Modul AG - www.data-modul.com... -
Page 34: System Panel Connector (F_Panel1)
The IDE LED lights up or flashes when data is read from or written to the HDD. Reset Button (2-pin RESET) This 2-pin connector is for the chassis-mounted reset button for system reboot without turning off the system power. Data Modul AG - www.data-modul.com... -
Page 35: Digital I/O Connector (Jdio01)
User’s Manual 1.8.8 Digital I/O Connector (JDIO01) 1.8.9 LVDS Connector (JLVDS1) IX57QM/IX55HM Data Modul AG - www.data-modul.com... -
Page 36: Lcd Inverter Connector (Jbkl1)
IX57QM/IX55HM 1.8.10 LCD Inverter Connector (JBKL1) Signal Description Signal Signal Description Bright adjust. Vadj=0.75V ~ 4.25V (Recommended: 4.7KΩ, > 1/16W) ENBKL LCD backlight ON/OFF control signal Data Modul AG - www.data-modul.com... -
Page 37: Spi Connector (Spi1)
This connector is for an additional Sony/Philips Digital Interface (S/PDIF) port(s). Connect the S/PDIF module cable to this connector, then install the module to a slot opening at the back of the system chassis. The S/PDIF module is purchased separately. IX57QM/IX55HM Data Modul AG - www.data-modul.com... -
Page 38: Serial Sata Connector (Sata1, Sata2, Sata3, Sata4)
Install the Windows® 2000 Service Pack 4 or the Windows® XP Service Pack1 before using Serial ATA. When using the connectors in Standard IDE mode, connect the primary (boot) hard disk drive to the SATA1 connector. Data Modul AG - www.data-modul.com... -
Page 39: Usb 2.0 Connector (Usb78, Usb56)
These USB connectors comply with USB 2.0 specification that supports up to 480 Mbps connection speed. USB78 USB78 USB56 USB56 Never connect a 1394 cable to the USB connectors. Doing so will damage the motherboard! The USB module is purchased separately. IX57QM/IX55HM Data Modul AG - www.data-modul.com... - Page 40 Adolfo Pérez Esquivel 3 Edificio Las Americas III Oficiana 40 28230 Parque Empresarial Madrid Las Rozas - Spain Tel.: +34-916 366 458 Data Modul Ltd. / UK 3 Brindley Place Birmingham B 12JB United Kingdom Tel.: +44-121-698-8641 Data Modul Inc. / USA...
