When the application is executed, it will display watchdog information in the WATCH-
DOG INFORMATION group box. It displays max timeout, min timeout, and timeout
steps in milliseconds. For example, a 1~255 seconds watchdog will have 255000
max timeout, 1000 min timeout, and 1000 timeout steps. You can test the functional-
ity of the watchdog as follows:
 Set the timeout value 3000 (3 sec.) in the SET TIMEOUT field and set the delay
value 2000 (2 sec.) in the SET DELAY field, then click the START button. The
Timeout Countdown field will countdown the watchdog timer and display 5000
(5 sec.).
 Before the timer counts down to zero, you can reset the timer by clicking the
REFRESH button. After you click this button, the Timeout Countdown field will
display the value of the SET TIMEOUT field.
 If you want to stop the watchdog timer, just click the STOP button.
Hardware Monitor
When the Monitor application is executed by clicking the button, hardware monitoring
data values will be displayed. If certain data values are not supported by the platform,
the correspondent data field will be grayed-out with a value of 0.
For more details on MIO-2261 software API, please contact your dealer or Advantech
AE.
