Page 1: User Manual
User Manual 1st Ed - Version: January 2013... - Page 2 ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com...
- Page 3 So please consult the user’s manual first. To receive the latest version of the user’s manual; please visit our Web site at: http://www.avalue.com.tw/ ECM-QM57 User’s Manual 3 Data Modul AG - www.data-modul.com...
- Page 4 Room 805, Building 9,No.99 Tianzhou Rd., 2F keduka-Bldg, 2-27-3 Taito, Caohejing Development Area, Taito-Ku, Tokyo 110-0016 Japan Xuhui District, Shanghai Tel: +81-3-5807-2321 Tel: +86-21-5169-3609 Fax:+86-21-5445-3266 Fax: +81-3-5807-2322 Information: sales.china@avalue.com.cn Information: sales.japan@avalue.com.tw Service: service@avalue.com.tw Service: service@avalue.com.tw ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com...
- Page 5 A product returned without proof of the purchase date is not eligible for warranty service. 5. Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer. ECM-QM57 User’s Manual 5 Data Modul AG - www.data-modul.com...
-
Page 6: Table Of Contents
SPI connector (JSPI1) ....................... 33 2.4.19 LVDS connector (JLVDS1) ......................34 2.4.20 USB connector 8 & 9/ 10 & 11 (JUSB45/ JUSB67)..............35 2.4.21 Power connector (PWRCON1) ....................35 Audio / USB Daughter Board User’s Guide.............36 ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... - Page 7 Intelligent Power Sharing ......................59 3.6.2.12 AMT Configuration ..........................60 3.6.3 Advanced Chipset Features......................61 3.6.3.1 North Bridge ............................62 3.6.3.2 South Bridge ............................63 3.6.3.2.1 PCI Express Ports Configuration ....................64 ECM-QM57 User’s Manual 7 Data Modul AG - www.data-modul.com...
- Page 8 Install Chipset Driver (For Intel QM57)..............72 Install Display Driver (For Intel QM57) ..............73 Install Audio Driver (For Realtek ALC888) ..............74 Install Ethernet Driver (For Intel 82574L/ 82577LM) ..........75 5. Mechanical Drawing ....................77 ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com...
-
Page 9: Getting Started
Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x 3.5＂ ECM-QM57 Micro Module 1 x Quick Installation Guide for ECM-QM57 1 x AUX-032 daughter board 1 x DVD-ROM contains the followings: —... -
Page 10: Document Amendment History
ECM-QM57 1.3 Document Amendment History Revision Date Comment September 2010 Initial Release ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 11: Manual Objectives
We strongly recommend that you study this manual carefully before attempting to interface with ECM-QM57 series or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance. -
Page 12: System Specifications
LCD/ Simultaneous Mode: 1600 x 1200 @ 75 Hz CRT + LVDS, HDMI + LVDS, CRT + HDMI Multiple Display Dual-channel 18/ 24-bit LVDS LVDS Audio Realtek ALC888 Supports 5.1-CH Audio AC97 Codec Mic-in, Line-in, Line-out Audio Interface ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... - Page 13 Operation Temperature -20 ~ 80°C (-68 ~ 176°F) Storage Temperature 0%~90% Relative Humidity, Non-condensing Operating Humidity 5.7" x 4" (146mm x 101mm) Size ( L x W ) 0.44lbs (0.2kg) Weight ECM-QM57 User’s Manual 13 Data Modul AG - www.data-modul.com...
-
Page 14: Architecture Overview - Block Diagram
ECM-QM57 1.6 Architecture Overview – Block Diagram The following block diagram shows the architecture and main components of ECM-QM57. ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 15: Data Modul Ag - Www.data-Modul.com
User’s Manual ECM-QM57 User’s Manual 15 Data Modul AG - www.data-modul.com... -
Page 16: Hardware Configuration
ECM-QM57 2. Hardware Configuration ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 17: Product Overview
User’s Manual 2.1 Product Overview ECM-QM57 User’s Manual 17 Data Modul AG - www.data-modul.com... -
Page 18: Installation Procedure
Note: Make sure the heat sink and the CPU top surface are in total contact to avoid CPU overheating problem that would cause the system to hang or unstable. ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 19: Main Memory
User’s Manual 2.2.1 Main Memory ECM-QM57 provides one 204-pin SODIMM non-ECC socket support up to DDR3 800/ 1066 SDRAM. The total maximum memory size is 4GB. SODIMM (Rear side) Make sure to unplug the power supply before adding or removing SODIMMs or other system components. -
Page 20: Data Modul Ag - Www.data-Modul.com
(2) Static electricity can damage the electronic components of the computer or optional boards. Before starting these procedures, ensure that you are discharged of static electricity by touching a grounded metal object briefly. ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 21: Jumper And Connector List
3 x 1 header, pitch 2.54 mm JBAT1 Serial port 1 pin 9 signal select 3 x 2 header, pitch 2.0 mm JRI1 Input power select 2 x 1 header, pitch 2.54 mm PWR_MSEL1 ECM-QM57 User’s Manual 21 Data Modul AG - www.data-modul.com... -
Page 22: Data Modul Ag - Www.data-Modul.com
SATA_PWR2 Serial ATA connector 1 SATA1 Serial ATA connector 2 SATA2 System fan connector 3 x 1 wafer, pitch 2.54 mm SYS_FAN1 USB connector 2 USB1 VGA connector D-sub 15-pin, female VGA1 ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 23: Setting Jumpers & Connectors
User’s Manual 2.4 Setting Jumpers & Connectors 2.4.1 Clear CMOS (JBAT1) Protect* Clear CMOS * Default 2.4.2 Serial port 1 pin 9 signal select (JRI1) Ring* +12V * Default ECM-QM57 User’s Manual 23 Data Modul AG - www.data-modul.com... -
Page 24: At/ Atx Input Power Select (Pwr_Msel1)
ECM-QM57 2.4.3 AT/ ATX Input power select (PWR_MSEL1) * Default 2.4.4 5VSB connector in ATX (PWR_SB) Signal ATX5VSB PSON ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 25: Signal Description -At/Atx Mode & Input Power Type
(PWR_MSEL1) Use ATX type power input, and set the board in AT mode. ATX Type (PWR_SB) ATX Mode (PWR_MSEL1) Use ATX type power input, and set the board in ATX mode. ECM-QM57 User’s Manual 25 Data Modul AG - www.data-modul.com... -
Page 26: Battery Connector (Bbat1)
ECM-QM57 2.4.5 Battery connector (BBAT1) Signal VBAT 2.4.6 CFAST LED connector (BLED1/ BLED2) Signal BLED2 BLED1 BLED1/ BLED2 ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 27: Cpu Fan Connector (Cpu_Fan1/ Sys_Fan1)
User’s Manual 2.4.7 CPU fan connector (CPU_FAN1/ SYS_FAN1) CPU_FAN1 SYS_FAN1 Signal CPU_FAN_PWR/ SYS_FAN_PWR CPUFANIN/ SYSFANIN 2.4.8 Serial port 1 in RS-422/485 mode (J422/485) Signal PIN PIN Signal 485RX- 485TX- 485RX+ 485TX+ ECM-QM57 User’s Manual 27 Data Modul AG - www.data-modul.com... -
Page 28: Audio Connector (Jaudio1)
ECM-QM57 2.4.9 Audio connector (JAUDIO1) Signal PIN PIN Signal MIC1_JD LIN1_JD FRONT_JD MIC1_L MIC1_R LIN1_L LIN1_R FRONT_L FRONT_R 2.4.10 +12V power Connector (JBKL1) Signal +12V ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 29: Lcd Backlight Brightness Adjustment (Jvr1)
2.4.11 LCD backlight brightness adjustment (JVR1) Signal BRIGHT Variation Resistor (Recommended: 4.7KΩ, >1/16W) 2.4.12 Low pin count connector (JLPC1) Signal PIN PIN Signal +5VSB INT_SERIRQ CLK_LPC LPC_AD3 LPC_FRAME# LPC_AD2 PLT_RST# LPC_AD1 +3.3V LPC_AD0 ECM-QM57 User’s Manual 29 Data Modul AG - www.data-modul.com... -
Page 30: Lcd Inverter Connector (Jbkl2)
VR signal controlled by JVR1. Please see the JVR1 section for detailed circuitry information. 2.4.13.1 Signal Description – LCD Inverter Connector (JBKL2) Signal Signal Description L_BKLT_CTRL_R Vadj = 0.75V ~ 4.25V (Recommended: 4.7KΩ, >1/16W) BLEN LCD backlight ON/OFF control signal ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 31: Led Backlight Adjustment Connector (Jbkl3/ Jbkl4)
User’s Manual 2.4.14 LED backlight adjustment connector (JBKL3/ JBKL4) Signal GPIO7/ DGPU_HPD_INTR# JBKL3 2.4.15 Serial port 2 connector (JCOM2) Signal PIN PIN Signal DCD2 RxDD2 TxDD2 DTR2 DSR2 RTS2 CTS2 ECM-QM57 User’s Manual 31 Data Modul AG - www.data-modul.com... -
Page 32: General Purpose I/O Connector (Jdio)
ECM-QM57 2.4.16 General purpose I/O connector (JDIO) Signal Signal DIO_GP20 DIO_GP10 DIO_GP21 DIO_GP11 DIO_GP22 DIO_GP12 DIO_GP23 DIO_GP13 DIO_GP24 DIO_GP14 DIO_GP25 DIO_GP15 DIO_GP26 DIO_GP16 DIO_GP27 DIO_GP17 SMBCLK_MAIN SMBDATA_MAIN ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 33: Miscellaneous Setting Connector (Jfp)
User’s Manual 2.4.17 Miscellaneous setting connector (JFP) Signal PEBT RST# PWR-LED HDD-LED COPEN# 2.4.18 SPI connector (JSPI1) Signal Signal +3.3V SPI_CS#0 SPI_CLK SPISO SPI_SI HOLD#_R ECM-QM57 User’s Manual 33 Data Modul AG - www.data-modul.com... -
Page 34: Lvds Connector (Jlvds1)
2.4.19 LVDS connector (JLVDS1) Signal PIN PIN Signal +3.3V +3.3V LVDS_DDC_DATA LVDS_DDC_CLK LVDSA_DATA0 LVDSA_DATA1 LVDSA_DATA0# LVDSA_DATA1# LVDSA_DATA2 LVDSA_DATA3 LVDSA_DATA2# LVDSA_DATA3# LVDSB_DATA0 LVDSB_DATA1 LVDSB_DATA0# LVDSB_DATA1# LVDSB_DATA2 LVDSB_DATA3 LVDSB_DATA2# LVDSB_DATA3# LVDSA_CLK LVDSB_CLK LVDSA_CLK# LVDSB_CLK# +12V +12V ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 35: Usb Connector 8 & 9/ 10 & 11 (Jusb45/ Jusb67)
2.4.20 USB connector 8 & 9/ 10 & 11 (JUSB45/ JUSB67) Signal PIN PIN Signal N8/ N10 P8/ P10 P9/ P11 N9 N11 JUSB45 JUSB67 2.4.21 Power connector (PWRCON1) Signal PIN PIN Signal ECM-QM57 User’s Manual 35 Data Modul AG - www.data-modul.com... -
Page 36: Audio / Usb Daughter Board User's Guide
5 x 2 header, pitch 2.54mm 2.54mm USB connector 2.0mm USB connector 5 x 2 header, pitch 2.0mm 2.0mm USB connector 5 x 2 header, pitch 2.0mm TV / Audio connector 8 x 2 header, pitch 2.54mm ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 37: Setting Jumper And Connector
Line out R SPK L SPK R Line in L Line in R TVGND TVGND COMP 2.0mm USB Connector (JP4) 2.0mm USB Connector (JP5) Signal PIN PIN Signal Signal PIN PIN Signal ECM-QM57 User’s Manual 37 Data Modul AG - www.data-modul.com... -
Page 38: Bios Setup
ECM-QM57 3. BIOS Setup ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 39: Introduction
If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked to. Press F1 to Continue, DEL to enter SETUP ECM-QM57 User’s Manual 39 Data Modul AG - www.data-modul.com... -
Page 40: Using Setup
Note: Some of the navigation keys differ from one screen to another. • To Display a Sub Menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “ ” pointer marks all sub menus. ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 41: Getting Help
Award and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. ECM-QM57 User’s Manual 41 Data Modul AG - www.data-modul.com... -
Page 42: Bios Setup
Use the system time option to set the system time. Manually enter hours, minutes and seconds. 3.6.1.3 System Time Use the system Date option to set the system date. Manually enter the day, month and year. ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 43: Advanced Menu
Enable or disable Boot Option for Legacy Launch PXE OpROM Enabled Network Devices Disabled, Enable or disable Boot Option for Legacy Launch Storage OpROM Enabled Mass storage devices With Option ROM. ECM-QM57 User’s Manual 43 Data Modul AG - www.data-modul.com... -
Page 44: Acpi Settings
Select the highest ACPI sleep state the S1 (CUP Stop Clock), system will enter, when the SUSPEND button ACPI Sleep State S3 (Suspend to RAM) is pressed. Disabled, Enables or Disables deep S5 function. Deep S5 Enabled ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 45: S5 Rtc Wake Settings
Use the S5 RTC wake setting to set system wake in fixed time. Item Options Description Enables or Disables wake on alarm event. Disabled, When enabled, system will wake on the Wake system with fixed time Enabled specified hr:min::sec. ECM-QM57 User’s Manual 45 Data Modul AG - www.data-modul.com... -
Page 46: Cpu Configuration
To turn on/ off prefetching of adjacent cache Adjacent Cache Line Prefetch Enabled lines. When enables, a VMM can utilize the Disabled, additional hardware capabilities provided by Intel Virtualization Technology Enabled Vanderpool Technology. ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... - Page 47 Extended user, Factory Turbo Mode Power Limit in Watts. Factory TDP Limit User, Supervisor Turbo-XE Mode Processor TDP Limit in 1/8 W granularity. 0 means using the TDP Limit factory-configured value. ECM-QM57 User’s Manual 47 Data Modul AG - www.data-modul.com...
-
Page 48: Sata Configuration
SATA mode AHCI mode, mode for SATA controller. RAID mode Disabled, Enabled/ Disabled Serial ATA Enhanced, Serial-ATA Controller 0 Controller 0. Compatible Disabled, Enabled/ Disabled Serial ATA Serial-ATA Controller 1 Enhanced Controller 0. ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 49: Intel Igd Swsci Opregion Configuration
This feature allows you to select 1280x1024 24/2, Panel Resolution that will be 1024x600 18/2, LCD Panel Type displayed depending on the LCD 1400x900 24/2, Panel. 1600x1200 18/2, 1280x768 18/1, 1680x1050 24/2, 1920x1080 24/2, ECM-QM57 User’s Manual 49 Data Modul AG - www.data-modul.com... -
Page 50: Intel Tdt (At-P) Configuration
ACPI ALS Driver. 3.6.2.6 Intel TDT (AT-p) Configuration Item Option Description Enabled, Enable/ Disabled TDT in BIOS for Disabled testing only. Set the number of times Recovery TDT Recovery attempts will be allowed. ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 51: Intel Txt (Lt) Configuration
Interface for system software to Disabled support trust decisions by end Secure Mode Extensions (SMX) user Hardware extension intended to Enabled, provide a higher level of trust and Intel TXT (LT) Support Disabled control. ECM-QM57 User’s Manual 51 Data Modul AG - www.data-modul.com... -
Page 52: Usb Configuration
This is a workaround for OSes without EHCI hand-off support. The EHCI ownership change should be claimed by EHCI driver. The Choices: Enabled, Disabled 3.6.2.8.3 Device Reset timeout USB mass storage device start Unit command timeout. The options are: 10, 20, 30, 40 sec. ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 53: Controller Timeout
The H/W Monitor shows the operating temperature, fan speeds and system voltages. Temperature SYSTIN temperature CPUTIN temperature Fan speed System Fan speed CPU Fan speed Voltage CPUVCORE VGFX 1.05V AVCC 3VCC 3VSB ECM-QM57 User’s Manual 53 Data Modul AG - www.data-modul.com... -
Page 54: Super Io Configuration
You can use this item to set up or change the Super IO configuration for FDD controllers, parallel ports and serial ports. Please refer to 3.6.2.10.1 and 3.6.2.10.2 for more information. 54 ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 55: Serial Port 0 Configuration
IO=3F8h; IRQ=4, IO=3F8h; IRQ=3,4,5,6,7,10,11,12 Use the change Settings option to IO=2F8h; IRQ=3,4,5,6,7,10,11,12 change the serial port IO port Change Settings IO=3E8h; IRQ=3,4,5,6,7,10,11,12 address and interrupt address. IO=2E8h; IRQ=3,4,5,6,7,10,11,12 ECM-QM57 User’s Manual 55 Data Modul AG - www.data-modul.com... -
Page 56: Serial Port 1 Configuration
IO port Change Settings IO=3E8h; IRQ=3,4,5,6,7,10,11,12 address and interrupt address. IO=2E8h; IRQ=3,4,5,6,7,10,11,12 UART 232, Change the Serial Port as RS232/ UART 422, UART 232 422 485 422/ 485. UART485 ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 57: Thermal Configuration
User’s Manual 3.6.2.11 Thermal Configuration 3.6.2.11.1 Platform thermal Configuration ECM-QM57 User’s Manual 57 Data Modul AG - www.data-modul.com... - Page 58 Enabled, CPU Alert pin enabled. CPU Alert Disabled Enabled, MCH Alert pin enabled.. MCH Alert Disabled Enabled, PCH Alert pin enabled. PCH Alert Disabled Enabled, DIMM Alert pin enabled. DIMM Alert Disabled ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com...
-
Page 59: Intelligent Power Sharing
MCH Power Limit Disabled Enabled, Max processor power clamp. Processor Power Limit Disabled Enabled, Max core power clamp. Core Power Limit Disabled EC uses SMBus, Choose runtime interface for PCH Run Time Interface ECM-QM57 User’s Manual 59 Data Modul AG - www.data-modul.com... -
Page 60: Amt Configuration
Intel® AMT function. You can use this item to perform Enabled, AMT/ME unconfigure without Unconfigure AMT/ME Disabled password operation. Enabled, This option will determine watch WatchDog Timer Disabled dog timer. ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 61: Advanced Chipset Features
User’s Manual 3.6.3 Advanced Chipset Features This setting configures the north bridge, south bridge and ME subsystem. Item Option Description Enable Enable/disabled Compatible Enable CRID Disabled Revision ID ECM-QM57 User’s Manual 61 Data Modul AG - www.data-modul.com... -
Page 62: North Bridge
This item allows you to select PCI/PEG, which graphics controller to use Initiate Graphic Adapter PEG/IGD, as the primary boot device. PEG/PCI Graphics turbo IMON current Min= 14, Max= 31 Graphics Turbo IMON Current values supported. ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 63: South Bridge
Definition Audio controller. Enabled, Enable/ Disable internal HDMI Azalia internal HDMI codec Disabled codec for Azalia. Enable, This item helps to enable or High Precision Timer Disabled disable high precision timer. ECM-QM57 User’s Manual 63 Data Modul AG - www.data-modul.com... -
Page 64: Pci Express Ports Configuration
This item allows you to re-assign the function numbers on a port by port basis. You can disable/hide any root port and still have functions 0 thru N-1 where N is the total number of enabled root ports. The choices: Disable, Enabled, Auto. ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 65: Usb Configuration
(EHCI) Enabled Enabled/Disabled RMH Support; Disabled AUTO: Enable RMH support on RMH support Auto Ibex Peak Bx stepping or above Enabled To enable or disable USB Ports USB Port 2/3/8/9/10/11 Disabled ECM-QM57 User’s Manual 65 Data Modul AG - www.data-modul.com... -
Page 66: Me Subsystem
End of Post Message Disabled end of post message of the ME Subsystem. Use the Execute MEBx option to Enabled, enable or disable the Intel® Execute MEBx Disabled Management Engine BIOS extension (MEBx). ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 67: Boot
RT code is executed above 1MB. Force BIOS, Set display mode for Option ROM. Option ROM Messages Keep Current Enabled, Enabled: Allows Option ROMs to trap int 19. Interrupt 19 Capture Disabled ECM-QM57 User’s Manual 67 Data Modul AG - www.data-modul.com... -
Page 68: Security
If only the User's password is set, then this is a power on password and must be entered to boot or enter the BIOS setup program. In the BIOS setup program, the User will have Administrator rights. By default, no password is specified. ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 69: Save & Exit
The setup program then exits and reboots the controller. 3.6.6.5 Save Changes Changes made to BIOS settings during this session are committed to NVRAM. The setup program remains active, allowing further changes. ECM-QM57 User’s Manual 69 Data Modul AG - www.data-modul.com... -
Page 70: Discard Changes
Once the local update is complete, this setting is automatically set to “Disabled”. This option must be set to “Enabled” when a local update is needed. ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 71: Drivers Installation
User’s Manual 4. Drivers Installation Note: Installation procedures and screen shots in this section are for your reference and may not be exactly the same as shown on your screen. ECM-QM57 User’s Manual 71 Data Modul AG - www.data-modul.com... -
Page 72: Install Chipset Driver (For Intel Qm57)
If the warning message appears while the installation Step 3. Click Next. process, click Continue to go on. Step 4. Click Finish to complete setup. Step1. Locate 「\Driver_Chipset\Intel\ QM57\ \infinst_autol.exe」. Step 2. Click Next. ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 73: Install Display Driver (For Intel Qm57)
Windows XP operation system. Step 3. Click Yes. Step 1. Locate「Driver_Video\Intel\ Step 4. Click Next. QM57\Setup.exe」. Step 2. Click Next. Step 5. Click Finish to complete setup. ECM-QM57 User’s Manual 73 Data Modul AG - www.data-modul.com... -
Page 74: Install Audio Driver (For Realtek Alc888)
Windows 2000 operation system. Step 3. Select Next to the next step. Step 1. Locate 「\Driver_Audio\Intel\ Step 4. Click Finish to complete the setup. 6300ESB ALC888\setup.exe」. Step 2. Select Next to the next step. ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com... -
Page 75: Install Ethernet Driver (For Intel 82574L/ 82577Lm)
Windows XP operation system. Step 1. Locate 「\Driver_Gigabit\Intel\ Step 4. Click Accept to continue. 82574L or 82577LM」and choose your system OS. Step 2. Click Next. Step 5. Click Next. ECM-QM57 User’s Manual 75 Data Modul AG - www.data-modul.com... - Page 76 ECM-QM57 Step 5. Click Install to next step. Step 6. Click Next to next step. Step 7. Click Finish to complete the setup. ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com...
-
Page 77: Mechanical Drawing
User’s Manual 5. Mechanical Drawing ECM-QM57 User’s Manual 77 Data Modul AG - www.data-modul.com... - Page 78 ECM-QM57 Unit: mm ECM-QM57 User’s Manual Data Modul AG - www.data-modul.com...
- Page 79 User’s Manual Unit: mm ECM-QM57 User’s Manual 79 Data Modul AG - www.data-modul.com...
- Page 80 WS9 8UG - United Kingdom Phone: +44-1922-457358 Data MoDul Inc. / uSa 275 Marcus Blvd, Unit K Hauppauge, NY 11788 - USA Phone: +1-631-951-0800 Data MoDul aG | landsberger Str. 322 | 80687 Munich | tel. +49-89-56017-0 | Fax +49-89-56017-119 | www.data-modul.com...
