Options - GeoVision GV-Mini User Manual

1.3 Options

Optional devices can expand your GV-Mini DVR V2's capabilities and versatility. Contact your
dealer for more information.
GV-Data Capture V3
Series
GV-I/O USB Box
GV-Hub Box
GV-COM Box
GV-DOM
(Disk on Module)
GV-Multi Quad Card
GV-Joystick
RAM
Hard Disk
Note:
1. The purchased GV-series cards will be added on the GV-Mini DVR V2 before shipment.
2. Note that the purchase of GV-Multi Quad Card will replace the default installation of
GV-Net I/O Card.
10
GV-Data Capture V3 can integrate the GV-Mini DVR V2 to an
electronic POS system, while GV-Data Capture V3E can
establish such integration through LAN or Internet.
GV-I/O USB Box provides 16 inputs and 16 relay outputs, and
up to 9 GV-I/O USB Boxes can chain together to expand the
use. However, 16 inputs are only supported when it is used
with GV-System version 8.2 or later.
An easy way for serial port extension. This hub can add 4
RS232/485 serial ports through the GV-Mini DVR V2's USB
port.
This unit can add 1 RS-232/RS-485 serial port through the
GV-Mini DVR V2's USB port.
DOM, a solid-state hard drive, is used for operating system
and system software to perform better under harsh conditions.
This card can take the video signal from the GV-Mini DVR V2
and then split it into 16 signals while maintaining video quality.
It can meet the need for multiple spot monitors.
GV-Joystick facilitates the PTZ camera control. It can be either
plugged into the GV-Mini DVR V2 for independent use or
connected to GV-Keyboard to empower the operation.
However, this device can only work on GV-System version 8.2
or later.
Multiple options for the amount of RAM are available to meet
different needs.
Multiple options for the HDD capacity are available to meet
different needs. A maximum of 3 HDDs, including one in Hot
Swap Drive Bay and two in GV-Mini DVR V2, can be installed.
