GV-800M V2
Owing to the installation of different GV Video Capture Cards, the rear panel may vary from
model to model of GV-Mini DVR V2 series.
Figure 2 presents the rear panel of GV-2008M V2, GV-2004M V2, GV-1480M V2, GV-1240M
V2 and GV-1120M V2. The figure below displays the rear panel of GV-800M V2. For the
names of other inputs and ports on the rear panel, please refer to Figure 2.
1
D-Type Audio Port
2
BNC Video Port x 4
Note: GV-800M V2 only supports 4 audio channels, so only port 1 to port 4 of the supplied
D-Type audio cable can work.
Figure 3
＊
Not functional
