Figure 2 Back Panel
Overview
Note: The arrows indicate the screws on the back of the unit that
need to be removed if you want to remove the cover. Three
additional screws on each side of the unit must also be
removed in order to lift the top cover.
1 68-pin SCSI connectors
2 Fan vent
3 Power connector
