System Overview
Sound
Short beep every
second
Chime 1 & 2
Chime 3
Aside from the indication sounds, the system also has a voice
confirmation of various events.
Note:
This table does not include actual alarm sounds.
Note that the audible indication of a fire zone differs
from that of a normal intrusion zone.

4.5 LED Indicators

This section describes the LED indicators of the power and
status indicators
LED Behavior
Power Green On when the system is ON. FLASHING when there is
LED
an AC power failure.
Status Red OFF when system is disarmed ON when system is
LED
armed. FLASHING during entry/exit delay, according to the
beep rate specified.
Page 20
Sounded When
An exit/entry delay is activated. (Beep sounded
every 0.5 seconds during last 10 seconds of delay.
Two (2) various chime sounds, when feature is
activated
Vocal announcement of "Zone Name" + Open
HomeLogiX HLX-40 User Guide
