System Overview

4. System Overview
The main components of the HomeLogiX HLX-40 wireless
TM
panel are:
• HomeLogiX HLX-40 Wireless Panel, Page 14
TM
• The LCD Display, Page 15
• The Keypad, Page 17
• Sound Indicators, Page 19
• LED Indicators, Page 20
TM
4.1 HomeLogiX HLX-40 Wireless Panel
The following figure presents the components of the wireless
panel.
Power
Menu
Indicator
Display
Status
Enter
Indicator
Keypad
Door
HLX-40
and
HLX-40A
Local sounder
Local Emergency
Button
Microphone
Figure 4: Components
Page 14 HomeLogiX HLX-40 User Guide
