The table below describes the components in the panel:
Menu
Power indicator
Status indicator
Keypad door
Local sounder
Microphone
Local emergency
button
Display
Enter
Note:
Panic Alarm is followed by a report to the Central
Station and audible siren as defined by the Installer.

4.2 The LCD Display

The LCD display clearly shows the system status. The display
consists of two rows. The bottom line is divided into two and
displays the system status and events.
When in Idle mode, the first line displays the system's name
(HomeLogiX by default) while the second line shows the
system status. For example, the second line displays Ready.
Pressing # (pound key), toggles the first line display between
the System name display and the Time & Date display.
The system status is displayed on the left of the bottom line.
The events are displayed on the right of the system status. If
there is more than one event, the event display toggles every
HomeLogiX HLX-40 User Guide
Use to navigate between menus
Power LED
Green On: system is ON. FLASHING: AC
power failure
Status LED
Red On: system armed.
Off: system disarmed.
Flash: entry and exit delay (according to
beep rate)
Open to access the keypad buttons
System speaker
Enables recording voice messages
Keep pressed for 3 seconds to sound a
standard panic alarm
LCD display
Accept an entry or selection
System Overview
Page 15
