System Overview
Table 2 describes the components in the panel:
Table 2: HomeLogiX™ HLX-40 Wireless Panel
Menu
Power indicator
Status indicator
Keypad door
Local sounder
Microphone
Local emergency button
Display
Enter
Panic Alarm is followed by a report to the Central Station and audible siren as
defined by the installer.
4.2

The LCD Display

The LCD display clearly shows the system status. The display consists of two
rows. The bottom line is divided into two and displays the system status and
events.
When in Idle mode, the first line displays the system's name (HomeLogiX™ by
default) while the second line shows the system status. For example, the
second line displays Ready.
Pressing # (pound key), toggles the first line display between the System name
display and the Time & Date display.
The system status is displayed on the left of the bottom line. The events are
displayed on the right of the system status. If there is more than one event, the
event display toggles every two seconds. There are several display options as
described in Table 3:
18
Use to navigate between menus
Power LED
Green on: system is ON
Green flashing: AC power failure
Status LED
Red on: system armed
Red off: system disarmed
Flash: entry and exit delay (according to beep rate)
Open to access the keypad buttons
System speaker
Enables recording voice messages
Keep pressed for 3 seconds to sound a standard panic
alarm
LCD display
Accept an entry or selection
HomeLogiX™ HLX-40 User Guide
