Power Socket; Unit Serial Number; Advanced Redundant Power System Socket; Reset Button - 3Com SuperStack II Switch 3000 10/100 User Manual

1-10 C 1: G
HAPTER ETTING

Power Socket

The Switch 3000 10/100 automatically adjusts to
the supply voltage. The fuse is suitable for both
110V A.C. and 220–240V A.C. operation. For infor-
mation on replacing fuses, refer to

Unit Serial Number

You may need this serial number for fault reporting
purposes.

Advanced Redundant Power System Socket

Use one of these sockets to connect a SuperStack II
Advanced Redundant Power System (RPS) to the
unit. You can use either socket. Refer to
ing an Advanced Redundant Power System
(Advanced RPS)" on

Reset Button

Using the reset button simulates a power-off/on
cycle. This has the same effect as carrying out a
reset via the VT100 interface; refer to
Switch 3000 10/100"

Console Port

Connect a terminal to the console port to carry out
remote or local out-of-band configuration and man-
agement. The console port is set to auto-baud, 8
data bits, no parity and 1 stop bit.
S
TARTED
Appendix A.
"Connect-
page 2-6.
"Resetting the
on page 4-28.

Plug-in Module Slot

Use this slot to install a Plug-in Module. The Module
can be used to provide an additional high speed link
to the rest of your network. 3Com provides a range
of Plug-in Modules; contact your supplier for avail-
ability.
When a Plug-in Module is not installed, ensure the
blanking plate is secured in place.

Ethernet Address

This label shows the unique Ethernet (or MAC)
address assigned to the unit.
