VLAN Configuration Mode Port / AutoSelect /
Unit Default This field allows you to specify how the
port is placed in a VLAN:
Port — The port uses Port VLAN Mode, which
means that the port is manually placed in the
required VLAN.
AutoSelect — The port uses AutoSelect VLAN
Mode, which means that the port is automatically
placed in the required VLAN by referring to a
VLAN Server database in 3Com's Transcend Enter-
prise Manager software.
Unit Default — The port uses Port VLAN Mode or
AutoSelect VLAN Mode depending on the con-
tents of the VLAN Configuration Mode field in
the Unit Setup screen. This is the default setting.
For more information, refer to
VLAN Mode" on page 5-4.
Broadcast Storm Control The Switch automati-
cally creates an alarm on each of its ports in order
to monitor the level of broadcast traffic on each
port. The Broadcast Storm Control fields allow you
to specify thresholds for the level of broadcast traffic
on a port, and specify an action to take place if the
threshold is exceeded.
Rising Threshold% This field allows you to specify
the percentage of broadcast traffic on the current
port which triggers the alarm for the port. The
default is 20%.
"Using AutoSelect
Setting Up the Switch Ports
Falling Threshold% This field allows you to specify
the percentage of broadcast traffic on the current
port required to reset the alarm for the port. The
falling threshold prevents the rising threshold
events being triggered continuously. The default is
10%.
Rising Action none / event / disable port /
disable port/notify / blip / blip port/notify Use this
field to specify the action for the alarm to take
when it reaches the rising threshold:
none — no action takes place
event — an SNMP trap is generated
disable port— the port is disabled
disable port/notify — the port is disabled and an
SNMP trap is generated
blip — the broadcast and multicast traffic on the
port is blocked for 5 seconds
blip port/notify — the broadcast and multicast
traffic on the port is blocked for 5 seconds, and
an SNMP trap is generated
If user defined appears as an option in the Rising
Action field, an unrecognized action has been speci-
fied using a MIB browser. You cannot select this
option.
4-15
