Setting up VLANs on the Switch 3000 10/100

The VLAN Setup screen allows you to:
Assign ports to VLANs, if those ports use Port
VLAN Mode.
View VLAN Setup information for the Switch.
To access the VLAN Setup screen:
From the Main Menu, select SWITCH MANAGE-
1
MENT. The Switch Management screen is displayed.
2 In the Management Level field, choose VLAN.
Choose the SETUP button. The VLAN Setup screen is
3
displayed as shown in
The screen shows the following:
A listbox containing three fields:
Port This field allows you to select the ID of the
port that you want to set up.
Type VLT / Standby / ATM / AutoSelect This field
displays information about the setup of the port:
VLT — The port is a VLT port. A Virtual LAN
Trunk (or VLT) is a Switch-to-Switch link which
carries traffic for all the VLANs on each
Switch. For more information about VLTs in
general, refer to
10/100" on page
a VLT port, refer to
Ports" on page
M
ANAGEMENT
Figure 5-6.
"VLANs and the Switch 3000
5-3. To specify that a port is
"Setting Up the Switch
4-12.
Figure 5-6 VLAN Setup screen
Standby — The port is the standby port of a
resilient link pair. The main port of the pair is
displayed in brackets. For more information
about resilient links, refer to
ient Links" on
ATM — The port is an ATM OC-3c Module
port. For more information, refer to the
"SuperStack II Switch ATM OC-3c Module User
Guide".
AutoSelect — The port uses AutoSelect VLAN
Mode. For more information about AutoSe-
lect VLAN Mode, refer to
VLAN Mode"
about how to configure VLANs using AutoSe-
lect VLAN Mode, refer to
Using AutoSelect VLAN Mode"
VLAN Membership This field displays the ID of
the VLAN(s) to which the port belongs.
"Setting Up Resil-
page 4-20.
"Using AutoSelect
on page 5-4. For information
"Setting Up VLANs
on page 5-10.
