Page 1: User Guide
SuperStack II Switch 3300 XM ® User Guide ® 3C16985 http://www.3com.com/ Part No. DUA1698-5AAA01 Published July 1999... - Page 2 Environmental Statement It is a 3Com policy to be environmentally friendly in all operations. This manual is printed on paper that comes from sustainable, managed European forests. The production process for making the pulp has a reduced AOX level (adsorbable organic halogen) resulting in elemental chlorine-free paper.
-
Page 3: Table Of Contents
ONTENTS BOUT UIDE Conventions Related Documentation Year 2000 Compliance Documentation Comments 3300 XM NTRODUCING THE WITCH About the SuperStack II Switch 3300 XM Summary of Features Switch 3300 XM — Front View Detail 10BASE-T/ 100BASE-TX Ports LEDs Switch 3300 XM — Rear View Detail Unit Information Label Power Socket Redundant Power System Socket... - Page 4 RJ45 Pin Assignments ECHNICAL PECIFICATIONS ECHNICAL UPPORT Online Technical Services World Wide Web Site 3Com Knowledgebase Web Services 3Com FTP Site 3Com Bulletin Board Service 3Com Facts Automated Fax Service Support from Your Network Supplier Support from 3Com Returning Products for Repair...
- Page 5 LOSSARY NDEX ORPORATION IMITED ARRANTY EMC S TATEMENTS...
-
Page 7: About This Guide
Most user guides and release notes are available in Adobe Acrobat Reader Portable Document Format (PDF) or HTML on the 3Com World Wide Web site: http://www.3com.com/... -
Page 8: Conventions
BOUT UIDE Conventions Table 1 Table 2 list conventions that are used throughout this guide. Table 1 Notice Icons Icon Notice Type Description Information note Information that describes important features or instructions Caution Information that alerts you to potential loss of data or potential damage to an application, system, or device Warning Information that alerts you to potential personal injury... -
Page 9: Related Documentation
Related Documentation Table 2 Text Conventions (continued) Convention Description Words in italics Italics are used to: Emphasize a point. Denote a new term at the place where it is defined in the text. Identify menu names, menu commands, and software button names. -
Page 10: Year 2000 Compliance
UIDE In addition, there are other publications you may find useful: Documentation accompanying the Advanced Redundant Power System. Year 2000 For information on Year 2000 compliance and 3Com products, visit the Compliance 3Com Year 2000 Web page: http://www.3com.com/products/yr2000.html Documentation Your suggestions are very important to us. They will help make our Comments documentation more useful to you. -
Page 11: Introducing The Switch 3300 Xm
3300 XM NTRODUCING THE WITCH This chapter contains introductory information about the Switch and how it can be used in your network. It covers the following topics: About the SuperStack II Switch 3300 XM Switch 3300 XM — Front View Detail Switch 3300 XM —... -
Page 12: About The Superstack Ii Switch 3300 Xm
100Mbps Switch 3300 XM backbone or server connection, and connects users to dedicated 100Mbps ports in one switch. In addition, as part of the 3Com ® SuperStack II range of products, you can combine it with any SuperStack II system as your network grows. -
Page 13: Switch 3300 Xm - Front View Detail
Switch 3300 XM — Front View Detail Switch 3300 XM — Front View Detail Figure 1 Switch 3300 XM — front view 10BASE-T/ The Switch has 24 auto-negotiating 10BASE-T/100BASE-TX ports 100BASE-TX Ports configured as MDIX (cross-over). These ports can be set to 10BASE-T half duplex, 10BASE-T full duplex, 100BASE-TX half duplex, 100BASE-TX full duplex, or they can automatically detect the speed and duplex mode of a link and provide the appropriate connection. - Page 14 1: I 3300 XM HAPTER NTRODUCING THE WITCH Table 3 LED behavior Color Indicates Port Status LEDs Packet Yellow Packets are being transmitted/received on the port. No packets are being transmitted/received on the port. Status Green A link is present, and the port is enabled. Green flashing A link is present, but the port is disabled.
-
Page 15: Switch 3300 Xm - Rear View Detail
Figure 2 Switch 3300 XM — rear view Unit Information This label shows the following: Label The 3Com product name of the Switch The 3Com 3C number of the Switch The unique MAC address (Ethernet address) of the Switch The serial number of the Switch You may need this information for fault reporting purposes. -
Page 16: Console Port
1: I 3300 XM HAPTER NTRODUCING THE WITCH Console Port The console port allows you to connect a terminal and perform remote or local out-of-band management. The console port uses standard null modem cable and is set to auto-baud, 8 data bits, no parity and 1 stop bit. -
Page 17: Network Configuration Examples
Network Configuration Examples Network The following illustrations show some examples of how the Switch can be Configuration used in your network. Examples The example in Figure 3 shows how a Switch 3300 XM stack can Switch 3300 XM as a Segmentation Switch segment a network of shared 10Mbps and 100Mbps connections. -
Page 18: Switch 3300 Xm As A Collapsed Backbone Switch
1: I 3300 XM HAPTER NTRODUCING THE WITCH Switch 3300 XM as a The example in Figure 4 shows how a Switch 3300 XM stack can act as a backbone for both shared and switched network segments. Collapsed Backbone Switch Figure 4 Using the Switch as a collapsed backbone... -
Page 19: Switch 3300 Xm As A Desktop Switch
Network Configuration Examples Switch 3300 XM as a The example in Figure 5 shows how a Switch 3300 XM can be used for a group of users that require dedicated 10Mbps or 100Mbps connections Desktop Switch to the desktop. The stack comprises a Switch 3300 XM and a Switch 3300 fitted with a SuperStack II Switch 1000BASE-SX module. -
Page 20: Configuration Rules For Fast Ethernet
1: I 3300 XM HAPTER NTRODUCING THE WITCH Configuration Rules The topology rules for 100Mbps Fast Ethernet are slightly different to for Fast Ethernet those for 10Mbps Ethernet. Figure 6 illustrates the key topology rules and provides examples of how they allow for large-scale Fast Ethernet networks. -
Page 21: Configuration Rules With Full Duplex
Configuration Rules with Full Duplex The key topology rules are: Maximum UTP cable length is 100m (328ft) over Category 5 cable. A 412m (1352ft) fiber run is allowed for connecting switch-to-switch, or endstation-to-switch, using half-duplex 100BASE-FX. A total network span of 325m (1066ft) is allowed in single-repeater topologies (one hub stack per wiring closet with a fiber run to the collapsed backbone). - Page 22 1: I 3300 XM HAPTER NTRODUCING THE WITCH...
-
Page 23: Installing The Switch
NSTALLING THE WITCH This chapter contains the information you need to install and set up the Switch. It covers the following topics: Choosing a Suitable Site Rack-mounting Placing Units On Top of Each Other Stacking Units The Power-up Sequence Choosing the Correct Cables Solving Problems Indicated by LEDs Managing the Switch WARNING: Safety Information. -
Page 24: Choosing A Suitable Site
2: I HAPTER NSTALLING THE WITCH Choosing a Suitable The Switch is suited for use in an office environment where it can be Site mounted in a standard 19-inch equipment rack, or free standing. Alternatively, the Switch can be rack-mounted in a wiring closet or equipment room. -
Page 25: Placing Units On Top Of Each Other
Placing Units On Top of Each Other Figure 7 Fitting a bracket for rack mounting 3 Insert the three screws and tighten with a suitable screwdriver. You must use the screws supplied with the mounting brackets. Damage caused to the unit by using incorrect screws invalidates your warranty. 4 Repeat steps 2 and 3 for the other side of the Switch. -
Page 26: Stacking Units
2: I HAPTER NSTALLING THE WITCH Stacking Units Units in the Switch 1100/3300 family can be stacked together and then treated as a single manageable unit with one IP address. You can stack Switch units together in two ways: The matrix port on the rear of the Switch allows you to connect two Switch units back-to-back. -
Page 27: Stacking Up To Four Units
Stacking Units Figure 8 A stack of two units Stacking Up To Four You can stack up to four Switch units using a single SuperStack II Switch Units 1100/3300 fitted with a Matrix Module and the appropriate number of Matrix Cables. You only need one Switch 1100/3300 fitted with a Matrix Module for each stack. - Page 28 2: I HAPTER NSTALLING THE WITCH 5 If you use the management software of the units: Ensure that all the units have the same version of management software Ensure that you re-configure the stack-wide features on all the units For more information about management software, see “Managing the Switch”...
-
Page 29: The Power-Up Sequence
The Power-up Sequence The Power-up The following sections describe how to get your Switch 3300 XM Sequence powered-up and ready for operation. You can connect a SuperStack II Advanced Redundant Power System Connecting a Redundant Power (part number 3C16071) to the Switch. This unit, which is also known as System an RPS, is designed to maintain the power to your Switch if a power supply failure occurs. -
Page 30: Choosing The Correct Cables
MDIX (cross-over). If you want to make a connection to another MDIX port, you need a cross-over cable. Most of the 10BASE-T and 100BASE-TX ports on 3Com devices are MDIX-only. Many ports on workstations and servers are configured as MDI (straight-through). If you want to make a connection to an MDI port, you need to use a standard straight-through cable. -
Page 31: Solving Problems Indicated By Leds
Solving Problems Indicated by LEDs Solving Problems If the LEDs on the Switch indicate a problem, refer to Table 5 which Indicated by LEDs contains a list of problems and suggested solutions. Table 5 Problems indicated by LEDs Problem Suggested Solution A Power LED does not Check that the power cable is firmly connected to the light... -
Page 32: Managing The Switch
2: I HAPTER NSTALLING THE WITCH Managing the The Switch contains software that allows you to change and monitor the Switch way it works. This management software is not required to get the Switch working, but if you do use it, you may improve the efficiency of the Switch and therefore improve the overall performance of your network. -
Page 33: Safety Information
AFETY NFORMATION You must read the following safety information before carrying out any installation or removal of components, or any maintenance procedures on the Switch 3300 XM. WARNING: Warnings contain directions that you must follow for your personal safety. Follow all directions carefully. You must read the following safety information carefully before you install or remove the unit. -
Page 34: Important Safety Information
A: S PPENDIX AFETY NFORMATION Important Safety Installation and removal of the unit must be carried out by qualified Information personnel only. If installing the Switch unit in a stack with SuperStack II Hub units, the Switch 3300 XM unit must be installed below the narrower Hub units. The unit should never be connected to an A.C. - Page 35 Important Safety Information France and Peru only: This unit cannot be powered from IT† supplies. If your supplies are of IT type, this unit must be powered by 230V (2P+T) via an isolation transformer ratio 1:1, with the secondary connection point labelled Neutral, connected directly to earth (ground).
-
Page 36: L'information De Sécurité Importante
A: S PPENDIX AFETY NFORMATION L’information de L'installation et la dépose de ce groupe doivent être confiés à un Sécurité Importante personnel qualifié. Si vous entassez l'unité Switch avec les unités SuperStack II Hub, l'unité Switch 3300 XM doit être installée en dessous des unités Hub plus étroites. - Page 37 L’information de Sécurité Importante L’appareil fonctionne à une tension extrêmement basse de sécurité qui est conforme à la norme CEI 950. Ces conditions ne sont maintenues que si l'équipement auquel il est raccordé fonctionne dans les mêmes conditions. France et Pérou uniquement: Ce groupe ne peut pas être alimenté...
-
Page 38: Wichtige Sicherheitsinformationen
A: S PPENDIX AFETY NFORMATION Wichtige Die Installation und der Ausbau des Geräts darf nur durch Sicherheitsinformat Fachpersonal erfolgen. ionen Wenn die Switch 3300 XM Einheit in einer Stapel mit anderen SuperStack II Hub Einheiten eingebaut werden soll, muß die Switch 3300 XM Einheit unter die schmaleren Hub Einheiten eingebaut werden. -
Page 39: Pin - Outs
OUTS Null Modem Cable 9-pin to RS-232 25-pin PC-AT Serial Cable 9-pin to 9-pin... -
Page 40: Modem Cable
B: P PPENDIX OUTS Modem Cable 9-pin to RS-232 25-pin RJ45 Pin Pin assignments are identical for 10BASE-T and 100BASE-TX RJ45 Assignments connectors Table 6 Pin assignments Pin Number Signal Function Ports configured as MDI TxData + Transmit data TxData – Transmit data RxData + Receive Data... - Page 41 RJ45 Pin Assignments Table 6 Pin assignments Pin Number Signal Function Ports configured as MDIX RxData + Receive Data RxData – Receive Data TxData + Transmit data Not assigned Not assigned TxData – Transmit data Not assigned Not assigned...
- Page 42 B: P PPENDIX OUTS...
- Page 43 ECHNICAL PECIFICATIONS Physical Dimensions Height: 76mm (3.0 in.) x Width: 483mm (19.0 in.) x Depth 300mm (12.0 in.) Weight: 4kg (8.8lbs) Environmental Requirements Operating Temperature 0° to 50°C (32° to 122°F) Storage Temperature –10° to +70°C (14° to 158°F) Operating Humidity 10–95% relative humidity, non-condensing Standards EN60068 (IEC68)—various parts...
-
Page 44: Technical Specifications
VLAN MIB (RFC 1573) ICMP (RFC 792) RMON MIB (RFC 1271) TCP (RFC 793) BOOTP (RFC 951) ARP (RFC 826) TFTP (RFC 783) Year 2000 Compliance For information on Year 2000 Compliance and 3Com products, visit the 3Com Year 2000 Web page: http://www.3Com.com/products/yr2000.html... -
Page 45: Technical Support
3Com recommends that you access the 3Com Corporation World Wide Web site. Online Technical 3Com offers worldwide product support 24 hours a day, 7 days a week, Services through the following online systems: World Wide Web site... -
Page 46: 3Com Ftp Site
3Com FTP Site Download drivers, patches, software, and MIBs across the Internet from the 3Com public FTP site. This service is available 24 hours a day, 7 days a week. To connect to the 3Com FTP site, enter the following information into... -
Page 47: 3Com Facts Automated Fax Service
Support from Your Network Supplier Access by Digital Modem ISDN users can dial in to the 3Com BBS using a digital modem for fast access up to 64 Kbps. To access the 3Com BBS using ISDN, call the following number:... - Page 48 D: T PPENDIX ECHNICAL UPPORT When you contact 3Com for assistance, have the following information ready: Product model name, part number, and serial number A list of system hardware and software, including revision levels Diagnostic error messages Details about recent configuration changes, if applicable...
-
Page 49: Returning Products For Repair
Returning Products for Repair Returning Products Before you send a product directly to 3Com for repair, you must first for Repair obtain an authorization number. Products sent to 3Com without authorization numbers will be returned to the sender unopened, at the sender’s expense. - Page 50 D: T PPENDIX ECHNICAL UPPORT...
- Page 51 LOSSARY 10BASE-T The IEEE specification for 10Mbps Ethernet over Category 3, 4 or 5 twisted pair cable. 100BASE-FX The IEEE specification for 100Mbps Fast Ethernet over fiber-optic cable. 100BASE-TX The IEEE specification for 100Mbps Fast Ethernet over Category 5 twisted-pair cable. auto-negotiation A feature on twisted pair ports that allows them to advertise their capabilities for speed, duplex and flow control.
- Page 52 LOSSARY broadcast storm Multiple simultaneous broadcasts that typically absorb all the available network bandwidth and can cause a network to fail. Broadcast storms can be due to faulty network devices. collision A term used to describe two colliding packets in an Ethernet network. Collisions are a part of normal Ethernet operation, but a sudden prolonged increase in the number of collisions can indicate a problem with a device, particularly if it is not accompanied by a general increase...
- Page 53 LOSSARY A device that regenerates LAN traffic so that the transmission distance of that signal can be extended. Hubs are similar to repeaters, in that they connect LANs of the same type; however they connect more LANs than a repeater and are generally more sophisticated. IEEE Institute of Electrical and Electronics Engineers.
- Page 54 LOSSARY MAC address Media Access Control address; also called hardware or physical address. A layer 2 address associated with a particular network device. Most devices that connect to a LAN have a MAC address assigned to them as they are used to identify other devices in a network. MAC addresses are 6 bytes long.
- Page 55 LOSSARY SNMP Simple Network Management Protocol. The current IETF standard protocol for managing devices on an TCP/IP network. stack A group of network devices that are integrated to form a single logical device. See Spanning Tree Protocol (STP). switch A device that interconnects several LANs to form a single logical LAN that comprises of several LAN segments.
- Page 56 LOSSARY...
- Page 57 NDEX Numbers hardware features 12 10BASE-T/100BASE-TX ports 13 3C number 15 3Com bulletin board service (3Com BBS) 46 3Com Knowledgebase Web Services 45 installing the Switch 23 3Com URL 45 prerequisites 24 3ComFacts 47 LEDs 13 auto-negotiating ports 13 Light Emitting Diodes. See LEDs...
- Page 58 16 power socket 15 technical support powering-up a Switch 3300 XM 29 product name 15 3Com Knowledgebase Web Services 45 3Com URL 45 bulletin board service 46 fax service 47 rack mounting a Switch 3300 XM 24 network suppliers 47 Redundant Power System.
- Page 59 If it appears that any product that is stated to meet this standard does not perform properly with regard to such date data on and after January 1, 2000, and Customer notifies 3Com before the later of April 1, 2000, or ninety (90) days after purchase of the product from 3Com or its authorized reseller, 3Com shall,...
- Page 60 Please refer to the Technical Support appendix in the User Guide for telephone numbers. Response to requests for telephone technical support will be in the form of a return call from a 3Com representative by close of business the following business day.
- Page 61 EMC S TATEMENTS FCC S TATEMENT This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
