Port ID 1 / 2 / 3 ... 13 This field displays the ID of
the port currently selected in the listbox.
VLAN ID 1 / 2 / 3 ...16 If the port specified in the
Port ID field uses Port VLAN Mode, this field allows
you to enter the ID of the VLAN to which the port is
to be assigned. If the port uses AutoSelect VLAN
Mode, you cannot specify the VLAN ID. By default,
all ports use Port VLAN Mode and belong to the
Default VLAN (VLAN 1). This field is not displayed if
the port is a VLT port.
If one or more ports use AutoSelect VLAN Mode,
you cannot use VLAN 15. Also, if you are using the
Spanning Tree Protocol, you cannot use VLAN 16. In
these cases, the relevant VLANs are used internally
by the Switch and are therefore not available.
APPLY This button applies any changes to the VLAN
database.
ATM LEC Setup If the port is an ATM OC-3c
Module port, this button allows you access the
VLAN LEC Setup screen for extending your VLANs
into an ATM network. For more information, refer
to the "SuperStack II Switch ATM OC-3c Module
User Guide".
Assigning a Port to a VLAN When Using Port
VLAN Mode
In the Port ID field, enter the ID of the required
1
port.
In the VLAN ID field, enter the ID of the required
2
VLAN.
Select APPLY.
3
CAUTION: Initially, all Switch ports belong to the
Default VLAN (VLAN 1). This VLAN is the only one
that allows an SNMP Network Manager to access
the management agent of the unit. If you remove
all ports from VLAN 1, an SNMP Network Manager
cannot manage the Switch.

Specifying that a Port is a VLT port

To specify that a port is a VLT port, refer to
ting Up the Switch Ports"
To create a VLT link, the ports on both ends of the
link must be VLT ports.
Virtual LANs (VLANs) 5-9
"Set-
on page 4-12.
