Module Description
Key Features
9-Port 1000BASE-SX
Gigabit Ethernet
Layer 2 Switching Module
Quick Start Guide
For the CoreBuilder
The 9-port 1000BASE-SX Gigabit Ethernet Layer 2 Switching Module
(Model Number 3CB9LG9MC) for the CoreBuilder
Switch can switch Gigabit Ethernet (GEN) connections to corporate
backbones and servers. The module has nine 1000BASE-SX GEN front
panel ports. It has the following number of backplane ports for
connection to the 24-port and the 9-port GEN Switch Fabric Modules:
Backplane Port
Connections to the
24-port GEN Switch
Fabric Module
7-slot Chassis
8-slot Chassis
16-slot Chassis
The 9-port Gigabit Ethernet Layer 2 Switching Module (9-port GEN
Layer 2 Switching Module) includes its own embedded management
agent that supports standard Simple Network Management Protocol
(SNMP) Management Information Bases (MIBs).
The 9-port GEN Layer 2 Switching Module supports these features:
Hot-swapping of modules
Management using the Administration Console
(a command line interface), the Web Management suite of
applications with an Internet browser, or SNMP-based applications
®
9000 Enterprise Switch
Backplane Port
Connections to the
9-port GEN Switch
Fabric Module
3
3
2
®
9000 Enterprise
1
1
NA
Advertisement
Table of Contents
Related Manuals for 3Com 3CB9LG9MC
Summary of Contents for 3Com 3CB9LG9MC
- Page 1 9000 Enterprise Switch Module Description The 9-port 1000BASE-SX Gigabit Ethernet Layer 2 Switching Module ® (Model Number 3CB9LG9MC) for the CoreBuilder 9000 Enterprise Switch can switch Gigabit Ethernet (GEN) connections to corporate backbones and servers. The module has nine 1000BASE-SX GEN front panel ports.
-
Page 2: Front Panel
9-Port 1000BASE-SX Gigabit Ethernet Layer 2 Switching Module Quick Start Guide For information about the software features that this module supports, see the: CoreBuilder 9000 Implementation Guide Command Reference Guide CoreBuilder 9000 Release Notes for the Fast Ethernet and Gigabit Ethernet Layer 2 Switching Modules Front Panel Figure 1 identifies the components on the module front panel. -
Page 3: Audience Description
Audience Description attempt to install, remove, or replace the 9-port GEN Layer 2 Switching Module if you have not had the proper training from 3Com. For training information in the United States and Canada, call 1-800-NET-3COM. For the number to call in other locations, visit the 3Com Web site: www.3Com.com/support/... -
Page 4: Handling Precautions
9-Port 1000BASE-SX Gigabit Ethernet Layer 2 Switching Module Quick Start Guide ESD Safety Information Electrostatic discharge (ESD) can damage components of the module. ESD, which occurs when the module is improperly handled, can cause complete or intermittent failures. CAUTION: To prevent ESD-related damage: Always wear an ESD wrist strap (not provided) when you handle a module, ensuring that the strap makes good skin contact and is properly grounded. -
Page 5: Unpacking Instructions
1 Verify that the module is the correct model by matching the 3C number that is listed on the shipping box label to the 3C number that you ordered (Model Number 3CB9LG9MC). 2 Remove the module, in its antistatic bag, from the shipping box. -
Page 6: Installation Prerequisites
9-Port 1000BASE-SX Gigabit Ethernet Layer 2 Switching Module Quick Start Guide Before you install the 9-port GEN Layer 2 Switching Module, make the Installation following preparations: Prerequisites Verify that the chassis is properly installed in a rack, on a table, or on a shelf, according to the instructions in either of these guides: 7-Slot Chassis Quick Installation Guide for the CoreBuilder 9000 Enterprise Switch... - Page 7 To optimize backplane performance, install the module in slot 1, 2, 3, 4, 5, 6, 7, 10, 11, or 12. 3Com recommends that you do not install the module in slot 13, 14, 15, or 16 because these slots have only one connection to the backplane.
- Page 8 9-Port 1000BASE-SX Gigabit Ethernet Layer 2 Switching Module Quick Start Guide Table 1 Mapping the 24-port GEN SFM and the 9-port GEN Switching Module to the 7-slot Chassis Number of SFM 9-port Switching SFM Backplane Port SFM LED Numbers Chassis Slot Backplane Ports Module Backplane Numbers Assigned...
- Page 9 9-Port 1000BASE-SX Gigabit Ethernet Layer 2 Switching Module Quick Start Guide Table 2 Mapping the 24-port GEN SFM and the 9-port GEN Switching Module to the 8-slot Chassis Number of SFM 9-port Switching SFM Backplane Port SFM LED Numbers Chassis Slot Backplane Ports Module Backplane Numbers Assigned...
- Page 10 9-Port 1000BASE-SX Gigabit Ethernet Layer 2 Switching Module Quick Start Guide Table 3 Mapping the 24-port GEN SFM and the 9-port GEN Switching Module to the 16-slot Chassis Number of SFM 9-port Switching SFM Backplane Port SFM LED Numbers Chassis Slot Backplane Ports Module Backplane Numbers Assigned...
- Page 11 9-Port 1000BASE-SX Gigabit Ethernet Layer 2 Switching Module Quick Start Guide Table 4 Mapping the 9-port GEN SFM and the 9-port GEN Switching Module to the 7-slot Chassis Number of SFM 9-port Switching SFM Backplane Port SFM LED Numbers Chassis Slot Backplane Ports Module Backplane Numbers Assigned...
-
Page 12: Installing The Module
Save this faceplate in case you need it in the future. Empty slots must be covered to ensure proper airflow and cooling in the chassis. 3Com recommends that you remove the faceplate only for the slot where you intend to install an individual module; leave the remaining faceplates in the chassis. - Page 13 9-Port 1000BASE-SX Gigabit Ethernet Layer 2 Switching Module Quick Start Guide Figure 2 Installing a 9-port GEN Switching Module into a 7-slot Chassis Gigabit Ethernet Switching Module ® CoreBuilder 9000 Spring-loaded screws...
- Page 14 Figure 3 Installing a 9-port GEN Switching Module into a 16-slot Chassis Spring-loaded screw ® CoreBuilder 9000 CoreBuilder ® 9000 Gigabit Ethernet Switching Module 3CB9FG24 3CB9FG24 3CB9FG24 3CB9FG24 3CB9FG24 3CB9FG24 3CB9FG24 3CB9FG24 3CB9FG24 3CB9FG24 3CB9FG24 3CB9FG24 3CB9LG9MC 3CB9LF20MM 3CB9LF20R Spring-loaded screw...
- Page 15 9-Port 1000BASE-SX Gigabit Ethernet Layer 2 Switching Module Quick Start Guide 7 To engage the module with the backplane, use both hands to perform the following steps: a Push firmly at the two ends of the front panel near the ejector handles until you feel the module connectors make firm contact with the backplane connectors.
- Page 16 9-Port 1000BASE-SX Gigabit Ethernet Layer 2 Switching Module Quick Start Guide The 9-port GEN Layer 2 Switching Module has one Module Status LED Verifying Module and nine Port Status LEDs on its front panel. Operation Watch the LEDs during the system power-on diagnostic test to verify proper module operation: On the Module Status LED, the normal power-on diagnostic test sequence is Green –...
-
Page 17: Administration Console
9-Port 1000BASE-SX Gigabit Ethernet Layer 2 Switching Module Quick Start Guide You can configure and manage the 9-port GEN Layer 2 Switching Module Managing the using several interfaces. The following sections describe two of the Module interfaces. Administration Console The Administration Console is the embedded menu-driven command line interface that you access from a terminal or through terminal emulation software. -
Page 18: Cabling Requirements
9-Port 1000BASE-SX Gigabit Ethernet Layer 2 Switching Module Quick Start Guide The following tables list the specifications for the module. Specifications Cabling Requirements Required Cable Type Maximum Segment Length Multimode fiber 500 meters 50 micron (1,640 feet) Multimode fiber 220 meters 62.5 micron (722 feet) Environmental Requirements... -
Page 19: Regulatory Compliance
9-Port 1000BASE-SX Gigabit Ethernet Layer 2 Switching Module Quick Start Guide Regulatory Compliance Safety Emissions CSA 22.2 No. 950 FCC Part 15 Class A EN 60950 ICES003 Class A IEC 60950 (formerly IEC 950) VCCI Class A UL 1950 EN 55022 Class A EN 60825 -1, -2 EN 50082-1 CE Mark... - Page 20 9-Port 1000BASE-SX Gigabit Ethernet Layer 2 Switching Module Quick Start Guide You can view and print these and other current CoreBuilder 9000 documents from the following sources: 3Com Web site http://support.3com.com/nav/switches.htm CoreBuilder 9000 Documentation CD-ROM This CD-ROM is included in the chassis shipping box. You can also...
-
Page 21: Imited Warranty
3Com warrants to the end user (“Customer”) that this hardware product will be free from defects in workmanship and materials, under normal use and service, for one (1) year from the date of purchase from 3Com or its authorized reseller. - Page 22 Advance Replacement is provided for ninety (90) days, after which time it may be available for a specified fee. 3Com will make commercially reasonable efforts to ship the replacement product not later than five (5) business days after receiving the request for advance replacement, but may be delayed due to product availability or export or import procedures.
- Page 23 MISSIONS OMPLIANCE TATEMENTS FOR LASS RODUCTS Federal Communications This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 Commission Notice of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 24 3Com registered trademarks are registered in the United States and may or may not be registered in other countries. 3Com, the 3Com logo, and CoreBuilder are registered trademarks of 3Com Corporation.
