Entering an IP Address for the Switch

Connect a terminal to the console port of the
1
Switch 3000 10/100, refer to
Terminal" on page
figured to 9600 line speed (baud rate), 8 data bits,
no parity and 1 stop bit.
Press [Return] one or more times until the Main
2
Banner screen appears.
At the Main Banner screen, press [Return] to dis-
3
play the Logon screen. Log on using the default
user name admin (no password is required). Select
OK.
The Main Menu is displayed. From this menu, select
4
the MANAGEMENT SETUP option. The Switch Man-
agement Setup screen is displayed.
On the Management Setup screen, fill in the follow-
5
ing fields:
Device IP Address
Device SubNet Mask (if necessary)
Default Router (if necessary)
For further information on the Management Setup
screen, refer to "Setting Up the Switch for Manage-
ment" on page 3-6.
If you need the Switch 3000 10/100 to send SNMP
6
traps to the Network Manager, you may need to set
up the address of the Network Manager in the Trap
Table. Refer to "Setting Up Traps"
"Connecting a VT100
2-7. The terminal should be con-
on page 4-25.
Quick Start For SNMP Users
3Com Network Managers such as Transcend Work-
Group Manager for Windows may automatically
configure the Switch 3000 10/100 to send traps to
them. Please read the documentation supplied with
your network management software.
When you have finished with the Management
7
Setup screen, select OK.
1-13
