SCAN ENGINE SETTINGS

The Reader Configuration Utility (ReaderConfig.exe) allows configuring the following
reader types, depending on the module equipped on your mobile computer:
1D Linear Imager (CCD)
1D Laser (SE950)
2D Imager
RFID reader
Options of different reader combination are allowed, such as 1D+RFID and 2D+RFID. For
each combination, both readers can be initialized and ready for scanning at the same
time (dual mode operation). For example, if you press the [SCAN] button while running
the ReaderConfig.exe utility on the mobile computer, it will read a barcode in position or
an RFID tag in proximity depending on which one comes first.
Note: (1) You cannot have 1D+2D scan engines installed on the mobile computer
because they are both barcode readers!
(2) You can run only one utility or application at a time to control the reader(s).
For example, while running ReaderConfig.exe, you should not run FORGE
Application Generator, STREAM Wireless Studio, MIRROR Browser, or any other
application that uses ReaderDLL.

SYMBOLOGIES SUPPORTED

Varying by the scan engine installed, the supported symbologies or tag types are listed
below. For details on configuring associated settings, please refer to each Appendix
separately.
Codabar
Code 11
Code 93
Composite Code
MSI
Plessey
Postal Codes
Telepen
Code 128 Code 128
GS1-128 (EAN-128)
ISBT 128
Appendix I
CCD, Laser 2D
161
